RAVENOL AWD-TOR FLUID is a special transmission oil for transfer cases of four-wheel drive systems from Torsen type of VW and AUDI. To improve the operating characteristics of intermittent loads, 4% of a particular friction modifier is used in the recipe RAVENOL AWD-TOR FLUID guarantees low wear and, thanks to its excellent properties, ensures a long service life of the gearbox.
Compliance with the requirements:
Castrol SAF-AG4 + FM, VW G 055 145
Equivalent: G055145A2 VAG VAG Axle Oil 1L.
Equivalents OEM:
Toyota 0888581086, Toyota 0888581086, VAG G055145A1, VAG G055145A2, VAG G055145S2
- Available packaging
- Product parameters
RAVENOL AWD-TOR FLUID is a special transmission oil for transfer cases of four-wheel drive systems from Torsen type of VW and AUDI. To improve the operating characteristics of intermittent loads, 4% of a particular friction modifier is used in the recipe RAVENOL AWD-TOR FLUID guarantees low wear and, thanks to its excellent properties, ensures a long service life of the gearbox.
Application Note
RAVENOL AWD-TOR FLUID is suitable for use in transfer cases of Torsen type four-wheel drive systems from VW, AUDI and other vehicle manufacturers.
RAVENOL AWD-TOR FLUID is excellently suited for use in normal road traffic as well as in motorsports.Observe manufacturer's instructions.
Characteristics
- An addition of 4% of a special friction modifier
- Excellent flowability at low temperatures
- Low wear
- High, stable viscosity index
- Reliable protection against wear, corrosion and foaming
- Excellent viscosity-temperature behavior
- Neutral behavior towards sealing materials
| Parameter | Unit | Value | Audit | |
|---|---|---|---|---|
| Brand | RAVENOL |
RAVENOL
|
||
| Type | Full synthetic |
Full synthetic
|
||
| Recomendations | Castrol SAF-AG4 + FM, VW G 055 145 |
Castrol SAF-AG4 + FM, VW G 055 145
|
||
| Compliant products | VW G 055 145 |
VW G 055 145
|
||
| Density at 20 °C | g/cm³ | 864 | EN ISO 12185 |
864
g/cm³
EN ISO 12185
|
| Color | Brown | visual |
Brown
visual
|
|
| Viscosity at 100 °C | mm²/s | 16.7 | DIN 51562-1 |
16.7
mm²/s
DIN 51562-1
|
| Viscosity at 40 °C | mm²/s | 107.9 | DIN 51562-1 |
107.9
mm²/s
DIN 51562-1
|
| Viscosity Index VI | 168 | DIN ISO 2909 |
168
DIN ISO 2909
|
|
| Brookfield Viscosity at -40 °C | mPa*s | 48.700 | ASTM D2983 |
48.700
mPa*s
ASTM D2983
|
| Pourpoint | °C | -54 | DIN ISO 3016 |
-54
°C
DIN ISO 3016
|
| VKA Four Ball Test (Wear) | mm | 0.71 | DIN 51350-3 |
0.71
mm
DIN 51350-3
|
| VKA Four Ball Test (EP Extreme Pressure) | N | 3600 / 3800 | DIN 51350-3 |
3600 / 3800
N
DIN 51350-3
|
| Seq. I at 24 °C | ml/ml | 0/0 | ASTM D892 |
0/0
ml/ml
ASTM D892
|
| Seq. II at 93,5 °C | ml/ml | 0/0 | ASTM D892 |
0/0
ml/ml
ASTM D892
|
| Seq. III at 24 °C after 93,5 °C | ml/ml | 0/0 | ASTM D892 |
0/0
ml/ml
ASTM D892
|
| Copper Strip Test at 150 °C | 1a | ASTM D130 |
1a
ASTM D130
|
|
| Approvals | Castrol SAF-AG4 + FM, VW G 055 145 |
Castrol SAF-AG4 + FM, VW G 055 145
|
