RAVENOL AWD-TOR FLUID is a special transmission oil for transfer cases of four-wheel drive systems from Torsen type of VW and AUDI. To improve the operating characteristics of intermittent loads, 4% of a particular friction modifier is used in the recipe RAVENOL AWD-TOR FLUID guarantees low wear and, thanks to its excellent properties, ensures a long service life of the gearbox.
Compliance with the requirements:
Castrol SAF-AG4 + FM, VW G 055 145
Equivalents OEM:
Toyota 0888581086, Toyota 0888581086, VAG G055145A1, VAG G055145A2, VAG G055145S2
- Available packaging
- Product parameters
RAVENOL AWD-TOR FLUID is a special transmission oil for transfer cases of four-wheel drive systems from Torsen type of VW and AUDI. To improve the operating characteristics of intermittent loads, 4% of a particular friction modifier is used in the recipe RAVENOL AWD-TOR FLUID guarantees low wear and, thanks to its excellent properties, ensures a long service life of the gearbox.
Application Note
RAVENOL AWD-TOR FLUID is suitable for use in transfer cases of Torsen type four-wheel drive systems from VW, AUDI and other vehicle manufacturers.
RAVENOL AWD-TOR FLUID is excellently suited for use in normal road traffic as well as in motorsports.Observe manufacturer's instructions.
Characteristics
- An addition of 4% of a special friction modifier
- Excellent flowability at low temperatures
- Low wear
- High, stable viscosity index
- Reliable protection against wear, corrosion and foaming
- Excellent viscosity-temperature behavior
- Neutral behavior towards sealing materials
Parameter | Unit | Value | Audit | |
---|---|---|---|---|
Brand | RAVENOL |
RAVENOL
|
||
Type | Full synthetic |
Full synthetic
|
||
Recomendations | Castrol SAF-AG4 + FM, VW G 055 145 |
Castrol SAF-AG4 + FM, VW G 055 145
|
||
Compliant products | VW G 055 145 |
VW G 055 145
|
||
Density at 20 °C | g/cm³ | 864 | EN ISO 12185 |
864
g/cm³
EN ISO 12185
|
Color | Brown | visual |
Brown
visual
|
|
Viscosity at 100 °C | mm²/s | 16.7 | DIN 51562-1 |
16.7
mm²/s
DIN 51562-1
|
Viscosity at 40 °C | mm²/s | 107.9 | DIN 51562-1 |
107.9
mm²/s
DIN 51562-1
|
Viscosity Index VI | 168 | DIN ISO 2909 |
168
DIN ISO 2909
|
|
Brookfield Viscosity at -40 °C | mPa*s | 48.700 | ASTM D2983 |
48.700
mPa*s
ASTM D2983
|
Pourpoint | °C | -54 | DIN ISO 3016 |
-54
°C
DIN ISO 3016
|
VKA Four Ball Test (Wear) | mm | 0.71 | DIN 51350-3 |
0.71
mm
DIN 51350-3
|
VKA Four Ball Test (EP Extreme Pressure) | N | 3600 / 3800 | DIN 51350-3 |
3600 / 3800
N
DIN 51350-3
|
Seq. I at 24 °C | ml/ml | 0/0 | ASTM D892 |
0/0
ml/ml
ASTM D892
|
Seq. II at 93,5 °C | ml/ml | 0/0 | ASTM D892 |
0/0
ml/ml
ASTM D892
|
Seq. III at 24 °C after 93,5 °C | ml/ml | 0/0 | ASTM D892 |
0/0
ml/ml
ASTM D892
|
Copper Strip Test at 150 °C | 1a | ASTM D130 |
1a
ASTM D130
|
|
Approvals | Castrol SAF-AG4 + FM, VW G 055 145 |
Castrol SAF-AG4 + FM, VW G 055 145
|
RAVENOL Getriebeoel SLS SAE 75W-140 GL 5 LS is PAO based with a specially coordinated additive treatment. This exceeds the needs of today's application requirements.
Compliance with the requirements:
Ford WSL-M2C 192-A, MIL-L-2105 D
Equivalent: G055145 VAG 1L.
- Available packaging
- Product parameters
Volume:
20 L
vendor code:
1221110-020
Volume:
20 L, ecobox
vendor code:
1221110-B20
Volume:
60 L
vendor code:
1221110-060
Volume:
60 L, print
vendor code:
1221110-D60
Volume:
1000 L
vendor code:
1221110-700
RAVENOL Getriebeoel SLS SAE 75W-140 GL 5 LS is PAO based with a specially coordinated additive treatment. This exceeds the needs of today's application requirements.
RAVENOL Getriebeoel SLS SAE 75W-140 GL 5 LS is outstanding for use as a rationalization product also with respect to the new generation of 5- and 6-gear manual transmissions and axle drives with and without limited slip differential. Especially suited for applications requiring "limited slip" (LS) properties.
Application Note
RAVENOL Getriebeoel SLS SAE 75W-140 GL 5 LS is a high-performance transmission oil for maintaining manual transmissions and rear axles in many popular vehicles. Also suitable for highly stressed hypoid axle gears as well as spur- and bevel gears, change gears in vehicles and work machines, and steering gears. Particularly suited for applications requiring "limited slip" (LS) properties.
Characteristics
- A high pressure stable lubricating film even at high oil temperatures and under high stress.
- Outstanding shearing stability and excellent thermal stability.
- Excellent viscosity-temperature properties.
- High oxidation stability.
- Excellent wear protection, outstanding EP properties.
- Low foaming properties even at high speeds.
- Good compatibility with non-ferrous metals and sealing materials.
- Good shifting behaviour even in low temperatures, low pour point.
- Extended life.
- Well adhering lubricating film and outstanding LS additive treatment for reduced transmission noise even when oil is hot.
Parameter | Unit | Value | Audit | |
---|---|---|---|---|
Brookfield Viscosity at -50 °C | mPa*s | 121.000 | ASTM D2983 |
121.000
mPa*s
ASTM D2983
|
Brand | RAVENOL |
RAVENOL
|
||
SAE | 75W-140 |
75W-140
|
||
Type | Synthetic |
Synthetic
|
||
API | GL-5 LS |
GL-5 LS
|
||
Recomendations | Ford WSL-M2C 192-A, MIL-L-2105 D |
Ford WSL-M2C 192-A, MIL-L-2105 D
|
||
Density at 20 °C | g/cm³ | 842.1 | EN ISO 12185 |
842.1
g/cm³
EN ISO 12185
|
Color | Yellow | visual |
Yellow
visual
|
|
Viscosity at 100 °C | mm²/s | 28.1 | DIN 51562-1 |
28.1
mm²/s
DIN 51562-1
|
Viscosity at 40 °C | mm²/s | 203.4 | DIN 51562-1 |
203.4
mm²/s
DIN 51562-1
|
Viscosity Index VI | 177 | DIN ISO 2909 |
177
DIN ISO 2909
|
|
Brookfield Viscosity at -40 °C | mPa*s | 127.600 | ASTM D2983 |
127.600
mPa*s
ASTM D2983
|
Pourpoint | °C | -51 | DIN ISO 3016 |
-51
°C
DIN ISO 3016
|
Flashpoint | °C | 220 | DIN EN ISO 2592 |
220
°C
DIN EN ISO 2592
|
Copper Strip Test at 121 °C | 1b | ASTM D130 |
1b
ASTM D130
|
|
Approvals | Ford WSL-M2C 192-A, MIL-L-2105 D |
Ford WSL-M2C 192-A, MIL-L-2105 D
|
