Oil for MAN TGX Euro 6 TGX 18.400 (4x2) EGR SCR (Euro 6) (year of issue from 2012 date to present). Motor, automatic transmission oil, transmission, antifreeze, gur fluid, brake fluid

Engine D 2066 LF61 EGR SCR Euro 6

Liquid volume (basic): 41.5 L

Ultra Synthetik Truck 5W-30

For diesels

This fuel saving lubricant has mainly been developed for heavy diesel engines even under the toughest operation conditions and all the year round use.

Manufacturer Approved:
Caterpillar ECF-3, Deutz DQC IV-18 LA, DTFR 15C100, DTFR 15C110, DTFR 15C120, Mack EOS-4.5, MAN M 3677, MTU Type 3.1, Renault RLD-3, Scania LDF-4, Volvo VDS-4.5

Compliance with the requirements:
Cummins CES 20081, Cummins CES 20086, DAF PSQL 2.1E LD, DDC 93K222, Deutz TTCD-Motors, DTFR 13D110 (MB 235.28), Ford WSS-M2C 213-A1, IVECO 18-1804 TLS E6, Liebherr LH-00-ENG LA, MAN M 3271-1, MAN M 3297-1, MAN M 3477, MAN M 3575, MAN M 3691, MAN M 3777, MB 228.31, MB 228.51, MB 235.28, MTU Type 2.1, Scania Low Ash, Voith Retarder B, Volvo CNG

show details

SAE: 5W-30

API: CJ-4, CK-4, SN

ACEA: E4, E6, E7, E8, E9, E11

Usage mode:

Replacement every 30000 KM or 12 MONTH.

Available packaging
Full description
Product parameters

Volume:
10 L

vendor code:
1121102-010

Code:
4014835847347

Volume:
20 L

vendor code:
1121102-020

Code:
4014835847361

Volume:
20 L, ecobox

vendor code:
1121102-B20

Volume:
60 L

vendor code:
1121102-060

Volume:
208 L

vendor code:
1121102-208

Code:
4014835847408

Volume:
208 L, print

vendor code:
1121102-D28

Volume:
1000 L

vendor code:
1121102-700

This fuel saving lubricant has mainly been developed for heavy diesel engines even under the toughest operation conditions and all the year round use.

RAVENOL Ultra Synthetik Truck SAE 5W-30 is suitable for application in engines with or without particle filters and exhaust catalysts. The SAE 5W-30 viscosity range ensures reliable cold starting at low ambient temperatures and full lubricity at high operating temperatures. The use of shearstable additives guarantees that the SAE grade 5W-30 is maintained throughout the entire oil change interval.

RAVENOL Ultra Synthetik Truck SAE 5W-30 is developed as SHPD Motoroil (Super High Performance Diesel). Extended oil change intervals according to manufacturer's specifications.

Application Note

RAVENOL Ultra Synthetik Truck SAE 5W-30 is a year round high performance motor oil, especially designed for economic use in exhaust-optimized engines with exhaust aftertreatment systems. Follow manufacturer's instructions.

Characteristics

Increased TBN
High wear protection
Outstanding oxidation stability
Excellent high temperature stability
Outstanding detergent and dispersant properties
Efficiency through low fuel consumption
Long service life due to high oxidation stability
Outstanding cold start behaviour, rapid engine oiling even at low temperatures
Very good viscosity-temperature behavior
Neutrality towards seals
Low oil consumption due to the low evaporation loss through PAO and HC base oils

Parameter	Unit	Value	Audit
Recommendations		Cummins CES 20081, Cummins CES 20086, DAF PSQL 2.1E LD, Detroit Diesel DDC 93K222, Deutz TTCD Motors, DTFR 13D110 (MB 235.28), Ford WSS-M2C213 A1, IVECO 18-1804 TLS E6, JASO DH-2, Liebherr LH-00-ENG LA, MAN 3297-1, MAN 3691, MAN M 3271-1, MAN M 3477, MAN M 3575, MAN M 3777, MB 228.31, MB 228.51, MB 235.28, MTU Typ 2.1, Scania LowAsh, Voith Retarder B, VOLVO CNG		Cummins CES 20081, Cummins CES 20086, DAF PSQL 2.1E LD, Detroit Diesel DDC 93K222, Deutz TTCD Motors, DTFR 13D110 (MB 235.28), Ford WSS-M2C213 A1, IVECO 18-1804 TLS E6, JASO DH-2, Liebherr LH-00-ENG LA, MAN 3297-1, MAN 3691, MAN M 3271-1, MAN M 3477, MAN M 3575, MAN M 3777, MB 228.31, MB 228.51, MB 235.28, MTU Typ 2.1, Scania LowAsh, Voith Retarder B, VOLVO CNG
SAE		5W-30		5W-30
Brand		RAVENOL		RAVENOL
Type		Synthetic		Synthetic
API		CJ-4, CK-4, SN		CJ-4, CK-4, SN
ACEA		E11, E4, E6, E7, E8, E9		E11, E4, E6, E7, E8, E9
JASO		DH-2		DH-2
Manufacturer Approved		Caterpillar ECF-3, Deutz DQC IV-18 LA, DTFR 15C100, DTFR 15C110, DTFR 15C120, Mack EOS-4.5, MAN M 3677, MTU Type 3.1, Renault RLD-3, Scania LDF-4, Volvo VDS-4.5		Caterpillar ECF-3, Deutz DQC IV-18 LA, DTFR 15C100, DTFR 15C110, DTFR 15C120, Mack EOS-4.5, MAN M 3677, MTU Type 3.1, Renault RLD-3, Scania LDF-4, Volvo VDS-4.5
Recomendations		Cummins CES 20081, Cummins CES 20086, DAF PSQL 2.1E LD, DDC 93K222, Deutz TTCD-Motors, DTFR 13D110 (MB 235.28), Ford WSS-M2C 213-A1, IVECO 18-1804 TLS E6, Liebherr LH-00-ENG LA, MAN M 3271-1, MAN M 3297-1, MAN M 3477, MAN M 3575, MAN M 3691, MAN M 3777, MB 228.31, MB 228.51, MB 235.28, MTU Type 2.1, Scania Low Ash, Voith Retarder B, Volvo CNG		Cummins CES 20081, Cummins CES 20086, DAF PSQL 2.1E LD, DDC 93K222, Deutz TTCD-Motors, DTFR 13D110 (MB 235.28), Ford WSS-M2C 213-A1, IVECO 18-1804 TLS E6, Liebherr LH-00-ENG LA, MAN M 3271-1, MAN M 3297-1, MAN M 3477, MAN M 3575, MAN M 3691, MAN M 3777, MB 228.31, MB 228.51, MB 235.28, MTU Type 2.1, Scania Low Ash, Voith Retarder B, Volvo CNG
Density at 20 °C	g/cm³	852	EN ISO 12185	852 g/cm³ EN ISO 12185
Color		Brown	visual	Brown visual
Viscosity at 100 °C	mm²/s	12.2	DIN 51562-1	12.2 mm²/s DIN 51562-1
Viscosity at 40 °C	mm²/s	73.6	DIN 51562-1	73.6 mm²/s DIN 51562-1
Viscosity Index VI		164	DIN ISO 2909	164 DIN ISO 2909
CCS Viscosity at -30 °C	mPa*s	5900	ASTM D5293	5900 mPa*s ASTM D5293
Low Temp. Pumping viscosity (MRV) at -35 °C	mPa*s	21.500	ASTM D4684	21.500 mPa*s ASTM D4684
Pourpoint	°C	-45	DIN ISO 3016	-45 °C DIN ISO 3016
Noack Volatility	%	11.8	ASTM D5800	11.8 % ASTM D5800
Flashpoint	°C	232	DIN EN ISO 2592	232 °C DIN EN ISO 2592
tbn	mgKOH/g	13.9	ASTM D2896	13.9 mgKOH/g ASTM D2896
Sulphated Ash	%wt.	0.97	DIN 51575	0.97 %wt. DIN 51575
Approvals		Caterpillar ECF-3, Cummins CES 20081, Cummins CES 20086, DAF PSQL 2.1E LD, DDC 93K222, Deutz DQC IV-18 LA, Deutz TTCD-Motors, DTFR 13D110 (MB 235.28), DTFR 15C100, DTFR 15C110, DTFR 15C120, Ford WSS-M2C 213-A1, IVECO 18-1804 TLS E6, Liebherr LH-00-ENG LA, Mack EOS-4.5, MAN M 3271-1, MAN M 3297-1, MAN M 3477, MAN M 3575, MAN M 3677, MAN M 3691, MAN M 3777, MB 228.31, MB 228.51, MB 235.28, MTU Type 2.1, MTU Type 3.1, Renault RLD-3, Scania LDF-4, Scania Low Ash, Voith Retarder B, Volvo CNG, Volvo VDS-4.5		Caterpillar ECF-3, Cummins CES 20081, Cummins CES 20086, DAF PSQL 2.1E LD, DDC 93K222, Deutz DQC IV-18 LA, Deutz TTCD-Motors, DTFR 13D110 (MB 235.28), DTFR 15C100, DTFR 15C110, DTFR 15C120, Ford WSS-M2C 213-A1, IVECO 18-1804 TLS E6, Liebherr LH-00-ENG LA, Mack EOS-4.5, MAN M 3271-1, MAN M 3297-1, MAN M 3477, MAN M 3575, MAN M 3677, MAN M 3691, MAN M 3777, MB 228.31, MB 228.51, MB 235.28, MTU Type 2.1, MTU Type 3.1, Renault RLD-3, Scania LDF-4, Scania Low Ash, Voith Retarder B, Volvo CNG, Volvo VDS-4.5

Mechanical gearbox ZF 16S-2220 16/2

Liquid volume (basic): 13 L

SSG Spec Synt LKW Getriebeol 75W-80

For gearbox

RAVENOL SSG Spec Synt LKW Getriebeoel 75W-80 is designed based on synthetic base oils and specially coordinated additive treatment. This exceeds the needs of today's application requirements.

Manufacturer Approved:
MAN 341 Type Z4, ZF TE-ML 01L, ZF TE-ML 02L, ZF TE-ML 16K

Compliance with the requirements:
DTFR 13D120 (MB 235.29), Eaton Extended drain, MAN 341 Type E3, MAN 341 Type VR, MAN 341 Type Z5, Voith Type C, Volvo 97305, Volvo 97307, ZF TE-ML 01E, ZF TE-ML 02E, ZF TE-ML 16P

show details

SAE: 75W-80

API: GL-4

Equivalents OEM:
Alpine 0101683, Alpine 0101684, Alpine 0101685, DAF 09052IT, DAF 09069EU, DAF 09069IT, DAF 09069RU, DAF 09225RU, DAF 09226BN, DAF 1659981, DAF 1659982, DAF 1659982G, DAF 1659988, DAF 1659988G, DAF 1659989, FEBI 170126, FEBI 170127, FEBI 170134, Hyundai Motor 0450000440, MAN 09110700672, Pentosin 1027107, Porsche 00004330300, Volvo 1161950, Volvo 85108170, Volvo 85108171, Volvo 85113903, Volvo 85113904, Volvo 85123561, Volvo 85123562, Volvo 85136277, Volvo 85136278 Alpine 0101683, Alpine 0101684, Alpine 0101685, DAF 09052IT, DAF 09069EU, DAF 09069IT, DAF 09069RU, DAF 09225RU, DAF 09226BN, DAF 1659981, DAF 1659982, DAF 1659982G, DAF 1659988, DAF 1659988G, DAF 1659989, FEBI 170126, FEBI 170127, FEBI 170134, Hyundai Motor 0450000440, MAN 09110700672, Pentosin 1027107, Porsche 00004330300, Volvo 1161950, Volvo 85108170, Volvo 85108171, Volvo 85113903, Volvo 85113904, Volvo 85123561, Volvo 85123562, Volvo 85136277, Volvo 85136278, Volvo MVBVISHIFT75W80JUG, Volvo VPO120548, Volvo VPO120548, Volvo VPO120549, ZF 0671090383, ZF 0671090384, ZF 0671090385, ZF 0671090386, ZF 671090383, ZF 671090384, ZF 671090385, ZF 671090386, ZF S0671090383, ZF S0671090384, ZF S0671090385, ZF S0671090386, ZF S671090385

Usage mode: normal

Replacement every 320000 KM or 24 MONTH.

Replacement every 500000 KM or 36 MONTH.

Available packaging
Full description
Product parameters

Volume:
1 L

vendor code:
1221100-001

Volume:
4 L

vendor code:
1221100-004

Volume:
10 L

vendor code:
1221100-010

Code:
4014835733848

Volume:
20 L

vendor code:
1221100-020

Code:
4014835733824

Volume:
20 L, ecobox

vendor code:
1221100-B20

Code:
4014835788121

Volume:
60 L

vendor code:
1221100-060

Code:
4014835733862

Volume:
60 L, print

vendor code:
1221100-D60

Volume:
208 L

vendor code:
1221100-208

Code:
4014835733886

Volume:
208 L, print

vendor code:
1221100-D28

Code:
4014835733800

Volume:
1000 L

vendor code:
1221100-700

RAVENOL SSG Spec Synt LKW Getriebeoel 75W-80 is designed based on synthetic base oils and specially coordinated additive treatment. This exceeds the needs of today's application requirements.

RAVENOL SSG Spec Synt LKW Getriebeoel 75W-80 is outstanding for use under severe mechanical and thermal stress on transmission oils, even with extended oil change intervals.

Application Note

RAVENOL SSG Spec Synt LKW Getriebeoel 75W-80 is a heavy duty transmission oil to care for synchronised manual transmissions in commercial vehicles with intarder or retarder. Shift comfort isnoticeably increased. Extreme oil change intervals according as specified by the manufacturer at up to 500,000 km reduce maintenance costs and increase cost-effectiveness.

Characteristics

Excellent thermal stability
High protection from rust, corrosion, foaming
Low solidification point
Excellent EP properties
Good shifting behaviour in low temperatures
Extended life
Fuel savings

Parameter	Unit	Value	Audit
Recommendations		DAF/VOLVO 97305, DAF/VOLVO 97307, DTFR 13D120 (MB 235.29), Eaton (Extended drain), IVECO, MAN 341 E3, MAN 341 VR, MAN 341 Z5, Renault, Voith Typ C, VOLVO 97317, ZF TE-ML 01E, ZF TE-ML 02E, ZF TE-ML 16P		DAF/VOLVO 97305, DAF/VOLVO 97307, DTFR 13D120 (MB 235.29), Eaton (Extended drain), IVECO, MAN 341 E3, MAN 341 VR, MAN 341 Z5, Renault, Voith Typ C, VOLVO 97317, ZF TE-ML 01E, ZF TE-ML 02E, ZF TE-ML 16P
Brand		RAVENOL		RAVENOL
SAE		75W-80		75W-80
Type		Synthetic		Synthetic
API		GL-4		GL-4
Manufacturer Approved		MAN 341 Type Z4, ZF TE-ML 01L, ZF TE-ML 02L, ZF TE-ML 16K		MAN 341 Type Z4, ZF TE-ML 01L, ZF TE-ML 02L, ZF TE-ML 16K
Recomendations		DTFR 13D120 (MB 235.29), Eaton Extended drain, MAN 341 Type E3, MAN 341 Type VR, MAN 341 Type Z5, Voith Type C, Volvo 97305, Volvo 97307, ZF TE-ML 01E, ZF TE-ML 02E, ZF TE-ML 16P		DTFR 13D120 (MB 235.29), Eaton Extended drain, MAN 341 Type E3, MAN 341 Type VR, MAN 341 Type Z5, Voith Type C, Volvo 97305, Volvo 97307, ZF TE-ML 01E, ZF TE-ML 02E, ZF TE-ML 16P
specification		MIL-L-2105		MIL-L-2105
Suitable for		IVECO, Renault		IVECO, Renault
Compliant products		Volvo 97317		Volvo 97317
Density at 20 °C	g/cm³	855	EN ISO 12185	855 g/cm³ EN ISO 12185
Color		Red	visual	Red visual
Viscosity at 100 °C	mm²/s	9.29	DIN 51562-1	9.29 mm²/s DIN 51562-1
Viscosity at 40 °C	mm²/s	51.97	DIN 51562-1	51.97 mm²/s DIN 51562-1
Viscosity Index VI		163	DIN ISO 2909	163 DIN ISO 2909
Brookfield Viscosity at -40 °C	mPa*s	38.800	ASTM D2983	38.800 mPa*s ASTM D2983
Pourpoint	°C	-42	DIN ISO 3016	-42 °C DIN ISO 3016
Flashpoint	°C	238	DIN EN ISO 2592	238 °C DIN EN ISO 2592
Copper Strip Test at 121 °C		1b	ASTM D130	1b ASTM D130
Approvals		DTFR 13D120 (MB 235.29), Eaton Extended drain, MAN 341 Type E3, MAN 341 Type VR, MAN 341 Type Z4, MAN 341 Type Z5, MIL-L-2105, Voith Type C, Volvo 97305, Volvo 97307, ZF TE-ML 01E, ZF TE-ML 01L, ZF TE-ML 02E, ZF TE-ML 02L, ZF TE-ML 16K, ZF TE-ML 16P		DTFR 13D120 (MB 235.29), Eaton Extended drain, MAN 341 Type E3, MAN 341 Type VR, MAN 341 Type Z4, MAN 341 Type Z5, MIL-L-2105, Voith Type C, Volvo 97305, Volvo 97307, ZF TE-ML 01E, ZF TE-ML 01L, ZF TE-ML 02E, ZF TE-ML 02L, ZF TE-ML 16K, ZF TE-ML 16P

Differential, rear HY-1350

Liquid volume (basic): 14.5 L

VSG 75W-90

For transmission

RAVENOL VSG SAE 75W-90 is designed based on high-quality synthetic base oils with a special additive treatment and inhibition ensuring trouble-free transmission function.

Compliance with the requirements:
BMW MTF-LT-4, BMW OSP, BMW SAF-XO, BOT 130 M, BOT 328, BOT 720, DAF LKW, DTFR 12B140 (MB 235.8), DTFR 13B110 (MB 235.11), Ford WSD-M2C 200-C, MAN 342 Type S1, MB 235.8, MB 235.9, MB 235.11, MB 235.21, MB 235.72, MIL-L-2105 D, Renault LKW, Scania STO 1:0, VW G 052 145, VW G 052 539, VW G 052 911, ZF TE-ML 12B, ZF TE-ML 16F, ZF TE-ML 17B

show details

SAE: 75W-90

API: GL-4, GL-5

Usage mode:

Replacement every 500000 KM or 36 MONTH.

Available packaging
Full description
Product parameters

Volume:
1 L

vendor code:
1221101-001

Code:
4014835733916

Volume:
4 L

vendor code:
1221101-004

Code:
4014835733992

Volume:
10 L

vendor code:
1221101-010

Code:
4014835733947

Volume:
20 L

vendor code:
1221101-020

Code:
4014835733923

Volume:
20 L, ecobox

vendor code:
1221101-B20

Code:
4014835846654

Volume:
60 L

vendor code:
1221101-060

Code:
2200000083081

Volume:
60 L, print

vendor code:
1221101-D60

Code:
4014835733930

Volume:
208 L

vendor code:
1221101-208

Code:
4014835733985

Volume:
208 L, print

vendor code:
1221101-D28

Code:
4014835733909

Volume:
1000 L

vendor code:
1221101-700

RAVENOL VSG SAE 75W-90 is designed based on high-quality synthetic base oils with a special additive treatment and inhibition ensuring trouble-free transmission function.

Application Note

RAVENOL VSG SAE 75W-90 is excellent for use of highly stressed axle drives.

RAVENOL VSG SAE 75W-90 is suitable for synchronised and non-synchronised manual transmissions, transfer cases and ancillary transmission requiring API GL-5 or GL-4 oil.

RAVENOL VSG SAE 75W-90 is suitable for Ford-transmission IB5, B5, MTX75, GM5, MT285/6, MMT6/6, MT75, R15M-D, R15MX-D, MT82 and Porsche Full-Time Transfer Case with Torsen (PL72T) for Cayenne 92A / 958 Diesel and S Hybrid from 2010 to 2018.

Characteristics

high additive reserves for prolonged oil change intervals according to the manufacturer specifications
excellent cold flow properties
best wear protection and best transmission efficiency
Fuel savings even with short distances in low outdoor temperatures
stable lubricating film even under high stress
extraordinary corrosion protection and good compatibility with non-ferrous metal
high oxidation resistance prevents oil thickening and deposits
outstanding dirt-carrying capacity, i.e. aggregates are clean even after very long oil change intervals
excellent elastomer compatibility to prevent leaks
extreme shearing stability, remains within the clean oil viscosity per SAE class 75W-90 even after very long periods of use
very high protection from rust, corrosion and foaming
extreme low pour point
excellent EP properties
fuel savings

Parameter	Unit	Value	Audit
Recommendations		BMW 83222339223 MTF-LT-4, BMW 83222365987, BMW 83229407768, BMW OSP, BMW SAF-XO, BOT 130 M, BOT 328, BOT 720, DAF LKW (für verlängerte Intervalle), DTFR 12B140 (MB 235.8), DTFR 13B110 (MB 235.11), Ford 1045737, Ford 5021033, Ford WSD-M2C200-C, IVECO, Land Rover TYK500010, MAN 342 S1, MB 235.11, MB 235.21, MB 235.72, MB 235.8, MB 235.9, MIL-L-2105 D, Porsche 000.043.305.04, Porsche 958.341.536.00 (Torsen 2010-2018), Renault LKW, Scania STO 1:0, VOLVO 97312, VOLVO 97315, VOLVO 97319, VW G 052 145 A2, VW G 052 539 A2, VW G 052 911 A2, ZF TE-ML 12B, ZF TE-ML 16F, ZF TE-ML 17B		BMW 83222339223 MTF-LT-4, BMW 83222365987, BMW 83229407768, BMW OSP, BMW SAF-XO, BOT 130 M, BOT 328, BOT 720, DAF LKW (für verlängerte Intervalle), DTFR 12B140 (MB 235.8), DTFR 13B110 (MB 235.11), Ford 1045737, Ford 5021033, Ford WSD-M2C200-C, IVECO, Land Rover TYK500010, MAN 342 S1, MB 235.11, MB 235.21, MB 235.72, MB 235.8, MB 235.9, MIL-L-2105 D, Porsche 000.043.305.04, Porsche 958.341.536.00 (Torsen 2010-2018), Renault LKW, Scania STO 1:0, VOLVO 97312, VOLVO 97315, VOLVO 97319, VW G 052 145 A2, VW G 052 539 A2, VW G 052 911 A2, ZF TE-ML 12B, ZF TE-ML 16F, ZF TE-ML 17B
Brand		RAVENOL		RAVENOL
SAE		75W-90		75W-90
Type		Full synthetic		Full synthetic
API		GL-4, GL-5		GL-4, GL-5
Recomendations		BMW MTF-LT-4, BMW OSP, BMW SAF-XO, BOT 130 M, BOT 328, BOT 720, DAF LKW, DTFR 12B140 (MB 235.8), DTFR 13B110 (MB 235.11), Ford WSD-M2C 200-C, MAN 342 Type S1, MB 235.11, MB 235.21, MB 235.72, MB 235.8, MB 235.9, MIL-L-2105 D, Renault LKW, Scania STO 1:0, VW G 052 145, VW G 052 539, VW G 052 911, ZF TE-ML 12B, ZF TE-ML 16F, ZF TE-ML 17B		BMW MTF-LT-4, BMW OSP, BMW SAF-XO, BOT 130 M, BOT 328, BOT 720, DAF LKW, DTFR 12B140 (MB 235.8), DTFR 13B110 (MB 235.11), Ford WSD-M2C 200-C, MAN 342 Type S1, MB 235.11, MB 235.21, MB 235.72, MB 235.8, MB 235.9, MIL-L-2105 D, Renault LKW, Scania STO 1:0, VW G 052 145, VW G 052 539, VW G 052 911, ZF TE-ML 12B, ZF TE-ML 16F, ZF TE-ML 17B
Suitable for		IVECO		IVECO
Compliant products		BMW 83222339223, BMW 83222365987, BMW 83229407768, Ford 1045737, Ford 5021033, Land Rover TYK500010, Porsche 000.043.305.04, Porsche 958.341.536.00, Volvo 97312, Volvo 97315, Volvo 97319, VW G 052 145, VW G 052 539, VW G 052 911		BMW 83222339223, BMW 83222365987, BMW 83229407768, Ford 1045737, Ford 5021033, Land Rover TYK500010, Porsche 000.043.305.04, Porsche 958.341.536.00, Volvo 97312, Volvo 97315, Volvo 97319, VW G 052 145, VW G 052 539, VW G 052 911
Density at 20 °C	g/cm³	839.8	EN ISO 12185	839.8 g/cm³ EN ISO 12185
Color		Yellow	visual	Yellow visual
Viscosity at 100 °C	mm²/s	16.8	DIN 51562-1	16.8 mm²/s DIN 51562-1
Viscosity at 40 °C	mm²/s	108.8	DIN 51562-1	108.8 mm²/s DIN 51562-1
Viscosity Index VI		168	DIN ISO 2909	168 DIN ISO 2909
Brookfield Viscosity at -40 °C	mPa*s	47.000	ASTM D2983	47.000 mPa*s ASTM D2983
Pourpoint	°C	-57	DIN ISO 3016	-57 °C DIN ISO 3016
Flashpoint	°C	224	DIN EN ISO 2592	224 °C DIN EN ISO 2592
Seq. I at 24 °C	ml/ml	0/0	ASTM D892	0/0 ml/ml ASTM D892
Seq. II at 93,5 °C	ml/ml	0/0	ASTM D892	0/0 ml/ml ASTM D892
Seq. III at 24 °C after 93,5 °C	ml/ml	0/0	ASTM D892	0/0 ml/ml ASTM D892
Copper Strip Test at 121 °C		1a	ASTM D130	1a ASTM D130
Approvals		BMW MTF-LT-4, BMW OSP, BMW SAF-XO, BOT 130 M, BOT 328, BOT 720, DAF LKW, DTFR 12B140 (MB 235.8), DTFR 13B110 (MB 235.11), Ford WSD-M2C 200-C, MAN 342 Type S1, MB 235.11, MB 235.21, MB 235.72, MB 235.8, MB 235.9, MIL-L-2105 D, Renault LKW, Scania STO 1:0, VW G 052 145, VW G 052 539, VW G 052 911, ZF TE-ML 12B, ZF TE-ML 16F, ZF TE-ML 17B		BMW MTF-LT-4, BMW OSP, BMW SAF-XO, BOT 130 M, BOT 328, BOT 720, DAF LKW, DTFR 12B140 (MB 235.8), DTFR 13B110 (MB 235.11), Ford WSD-M2C 200-C, MAN 342 Type S1, MB 235.11, MB 235.21, MB 235.72, MB 235.8, MB 235.9, MIL-L-2105 D, Renault LKW, Scania STO 1:0, VW G 052 145, VW G 052 539, VW G 052 911, ZF TE-ML 12B, ZF TE-ML 16F, ZF TE-ML 17B

Hydraulic power steering dual-braking ZF Servocom

Liquid volume (basic): 16 L

ATF Dexron II E

Transmission fluid

Application NoteRAVENOL ATF Dexron II E is developed for use in automatic transmission and torque converter transmission and power shift transmission with required specification.

Manufacturer Approved:
Allison C-4, MB-Approval 236.8, Voith H55.6336.3x Extended Drain (G1363)

Compliance with the requirements:
Caterpillar TO-2, DTFR 13C150 (MB 236.8), MAN 339 Type V2, MAN 339 Type Z2, MB 236.5, ZF TE-ML 04D, ZF TE-ML 09X, ZF TE-ML 14B, ZF TE-ML 16L

show details

Equivalents OEM:
Alpine 0100641, Alpine 0100642, Alpine 0100643, Alpine 0100644, Alpine 0100645, Alpine 100641, Alpine 100642, Alpine 100643, Alpine 100644, Alpine 100645, Alpine 100645, Land Rover STC8261

Usage mode: normal

Available packaging
Full description
Product parameters

Volume:
1 L

vendor code:
1211103-001

Code:
4014835732612

Volume:
4 L

vendor code:
1211103-004

Code:
4014835732698

Volume:
10 L

vendor code:
1211103-010

Code:
4014835732643

Volume:
20 L

vendor code:
1211103-020

Volume:
20 L, ecobox

vendor code:
1211103-B20

Volume:
60 L

vendor code:
1211103-060

Volume:
60 L, print

vendor code:
1211103-D60

Code:
4014835732636

Volume:
208 L

vendor code:
1211103-208

Volume:
208 L, print

vendor code:
1211103-D28

Volume:
1000 L

vendor code:
1211103-700

Application Note

RAVENOL ATF Dexron II E is developed for use in automatic transmission and torque converter transmission and power shift transmission with required specification.

RAVENOL ATF Dexron II E is recommended if ATF Type Dexron II E is to be used according to manufacturer’s specification.

Characteristics

reliable protection against wear, sludge, adhesion and corrosion
a very shear stable viscosity-temperature behaviour
can be used both at very low and very high temperatures
an extremely high thermal load
no foaming, even under the heaviest loads
compatibility with sealing materials

Parameter	Unit	Value	Audit
ATF		Dexron II E		Dexron II E
Recommendations		Caterpillar TO-2, DTFR 13C150 (MB 236.8), MAN 339 V2, MAN 339 Z2, MB 236.5, ZF TE-ML 04D, ZF TE-ML 09X, ZF TE-ML 14B, ZF TE-ML 16L		Caterpillar TO-2, DTFR 13C150 (MB 236.8), MAN 339 V2, MAN 339 Z2, MB 236.5, ZF TE-ML 04D, ZF TE-ML 09X, ZF TE-ML 14B, ZF TE-ML 16L
Brand		RAVENOL		RAVENOL
Type		Synthetic		Synthetic
Manufacturer Approved		Allison C-4, MB-Approval 236.8, Voith H55.6336.3x Extended Drain (G1363)		Allison C-4, MB-Approval 236.8, Voith H55.6336.3x Extended Drain (G1363)
Recomendations		Caterpillar TO-2, DTFR 13C150 (MB 236.8), MAN 339 Type V2, MAN 339 Type Z2, MB 236.5, ZF TE-ML 04D, ZF TE-ML 09X, ZF TE-ML 14B, ZF TE-ML 16L		Caterpillar TO-2, DTFR 13C150 (MB 236.8), MAN 339 Type V2, MAN 339 Type Z2, MB 236.5, ZF TE-ML 04D, ZF TE-ML 09X, ZF TE-ML 14B, ZF TE-ML 16L
specification		Ford MERCON®, GM Dexron® II E		Ford MERCON®, GM Dexron® II E
Density at 20 °C	g/cm³	834	EN ISO 12185	834 g/cm³ EN ISO 12185
Color		Red	visual	Red visual
Viscosity at 100 °C	mm²/s	7.5	DIN 51562-1	7.5 mm²/s DIN 51562-1
Viscosity at 40 °C	mm²/s	32	DIN 51562-1	32 mm²/s DIN 51562-1
Viscosity at -40 °C	mPa*s	8.3	ASTM D2983	8.3 mPa*s ASTM D2983
Viscosity Index VI		191	DIN ISO 2909	191 DIN ISO 2909
Pourpoint	°C	-57	DIN ISO 3016	-57 °C DIN ISO 3016
Flashpoint	°C	226	DIN EN ISO 2592	226 °C DIN EN ISO 2592
tbn	mgKOH/g	1.7	ASTM D2896	1.7 mgKOH/g ASTM D2896
Approvals		Allison C-4, Caterpillar TO-2, DTFR 13C150 (MB 236.8), Ford MERCON®, GM Dexron® II E, MAN 339 Type V2, MAN 339 Type Z2, MB 236.5, MB 236.8, Voith H55.6336.3x Extended Drain (G1363), ZF TE-ML 04D, ZF TE-ML 09X, ZF TE-ML 14B, ZF TE-ML 16L		Allison C-4, Caterpillar TO-2, DTFR 13C150 (MB 236.8), Ford MERCON®, GM Dexron® II E, MAN 339 Type V2, MAN 339 Type Z2, MB 236.5, MB 236.8, Voith H55.6336.3x Extended Drain (G1363), ZF TE-ML 04D, ZF TE-ML 09X, ZF TE-ML 14B, ZF TE-ML 16L

ATF Dexron III H

For automatic transmission

RAVENOL ATF DEXRON III H is universal ATF (Automatic Transmission Fluid) for all automatic transmission with and without controlled torque converter lockup clutch (so-called GKÜB = gear-clutch-lock) which are required for the transmission fluid type Dexron III H.

Manufacturer Approved:
Allison C-4, Allison TES-389, Voith H55.6336.3x Extended Drain (G1363), ZF TE-ML 04D, ZF TE-ML 14B, ZF TE-ML 20B, ZF TE-ML 25B

Compliance with the requirements:
Caterpillar TO-2, DTFR 13C100 (MB 236.1), DTFR 13C170 (MB 236.9), Ford MERCON®, MAN 339 L1, MAN 339 Type V1, MAN 339 Type Z1, MAN 339 Type Z2, MB 236.1, MB 236.5, MB 236.6, MB 236.9, MB 236.10, Volvo 97341, ZF TE-ML 02F, ZF TE-ML 03D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 16L, ZF TE-ML 16R, ZF TE-ML 17C

show details

Usage mode: normal

Available packaging
Full description
Product parameters

Volume:
1 L

vendor code:
1212100-001

Code:
4014835732810

Volume:
4 L

vendor code:
1212100-004

Code:
4014835732896

Volume:
10 L

vendor code:
1212100-010

Code:
4014835732841

Volume:
20 L

vendor code:
1212100-020

Code:
4014835732827

Volume:
20 L, ecobox

vendor code:
1212100-B20

Code:
4014835787025

Volume:
60 L

vendor code:
1212100-060

Code:
4014835732865

Volume:
60 L, print

vendor code:
1212100-D60

Code:
4014835732834

Volume:
208 L

vendor code:
1212100-208

Code:
4014835732889

Volume:
208 L, print

vendor code:
1212100-D28

Code:
4014835732803

Volume:
1000 L

vendor code:
1212100-700

RAVENOL ATF DEXRON III H is universal ATF (Automatic Transmission Fluid) for all automatic transmission with and without controlled torque converter lockup clutch (so-called GKÜB = gear-clutch-lock) which are required for the transmission fluid type Dexron III H.

Application Note

RAVENOL ATF DEXRON III H was developed for use in automatic transmissions with electronically controlled converter lockup clutch.

RAVENOL ATF DEXRON III H is especially suitable for use in transmissions with ATF Dexron III H specification.

RAVENOL ATF DEXRON III H is backwards compatible and can be used in transmissions with specification ATF Dexron F III.

RAVENOL ATF DEXRON III H is mixable with all ATF brands. It is advised to rinse with RAVENOL ATF DEXRON III H before, beforehand the final filling with RAVENOL ATF DEXRON III H is made.

Characteristics

Very good lubricating properties even at low temperatures in winter
High and stable viscosity index
Very low flow point
Excellent oxidation stability
Extensive protection against wear, corrosion and foaming
Well-tuned friction properties
Neutral behaviour towards sealing materials
Neutral behaviour by inhibition towards non-ferrous metals

Parameter	Unit	Value	Audit
ATF		Dexron III H		Dexron III H
Recommendations		Caterpillar TO-2, DTFR 13C100 (MB 236.1), DTFR 13C170 (MB 236.9), Ford MERCON® M-940717, MAN 339 L1, MAN 339 V1, MAN 339 Z1, MAN 339 Z2, MB 236.1, MB 236.10, MB 236.5, MB 236.6, MB 236.9, Nissan, Volvo 1161521, Volvo 1161621, VOLVO Transmission Oil 97341, ZF TE-ML 02F, ZF TE-ML 03D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 16L, ZF TE-ML 16R, ZF TE-ML 17C		Caterpillar TO-2, DTFR 13C100 (MB 236.1), DTFR 13C170 (MB 236.9), Ford MERCON® M-940717, MAN 339 L1, MAN 339 V1, MAN 339 Z1, MAN 339 Z2, MB 236.1, MB 236.10, MB 236.5, MB 236.6, MB 236.9, Nissan, Volvo 1161521, Volvo 1161621, VOLVO Transmission Oil 97341, ZF TE-ML 02F, ZF TE-ML 03D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 16L, ZF TE-ML 16R, ZF TE-ML 17C
Brand		RAVENOL		RAVENOL
Type		Synthetic		Synthetic
Manufacturer Approved		Allison C-4, Allison TES-389, Voith H55.6336.3x Extended Drain (G1363), ZF TE-ML 04D, ZF TE-ML 14B, ZF TE-ML 20B, ZF TE-ML 25B		Allison C-4, Allison TES-389, Voith H55.6336.3x Extended Drain (G1363), ZF TE-ML 04D, ZF TE-ML 14B, ZF TE-ML 20B, ZF TE-ML 25B
Recomendations		Caterpillar TO-2, DTFR 13C100 (MB 236.1), DTFR 13C170 (MB 236.9), Ford MERCON®, MAN 339 L1, MAN 339 Type V1, MAN 339 Type Z1, MAN 339 Type Z2, MB 236.1, MB 236.10, MB 236.5, MB 236.6, MB 236.9, Volvo 97341, ZF TE-ML 02F, ZF TE-ML 03D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 16L, ZF TE-ML 16R, ZF TE-ML 17C		Caterpillar TO-2, DTFR 13C100 (MB 236.1), DTFR 13C170 (MB 236.9), Ford MERCON®, MAN 339 L1, MAN 339 Type V1, MAN 339 Type Z1, MAN 339 Type Z2, MB 236.1, MB 236.10, MB 236.5, MB 236.6, MB 236.9, Volvo 97341, ZF TE-ML 02F, ZF TE-ML 03D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 16L, ZF TE-ML 16R, ZF TE-ML 17C
specification		Allison C-4, Allison TES-389, GM Dexron® II E, GM DEXRON® III F, GM Dexron® III H		Allison C-4, Allison TES-389, GM Dexron® II E, GM DEXRON® III F, GM Dexron® III H
Suitable for		Nissan		Nissan
Compliant products		Volvo 1161521, Volvo 1161621		Volvo 1161521, Volvo 1161621
Density at 20 °C	g/cm³	847	EN ISO 12185	847 g/cm³ EN ISO 12185
Color		Red	visual	Red visual
Viscosity at 100 °C	mm²/s	7.2	DIN 51562-1	7.2 mm²/s DIN 51562-1
Viscosity at 40 °C	mm²/s	33.9	DIN 51562-1	33.9 mm²/s DIN 51562-1
Viscosity Index VI		185	DIN ISO 2909	185 DIN ISO 2909
Brookfield Viscosity at -40 °C	mPa*s	14.200	ASTM D2983	14.200 mPa*s ASTM D2983
Pourpoint	°C	-51	DIN ISO 3016	-51 °C DIN ISO 3016
Flashpoint	°C	210	DIN EN ISO 2592	210 °C DIN EN ISO 2592
Seq. I at 24 °C	ml/ml	0/0	ASTM D892	0/0 ml/ml ASTM D892
Seq. II at 93,5 °C	ml/ml	0/0	ASTM D892	0/0 ml/ml ASTM D892
Seq. III at 24 °C after 93,5 °C	ml/ml	0/0	ASTM D892	0/0 ml/ml ASTM D892
Copper Strip Test at 121 °C		1b	ASTM D130	1b ASTM D130
tbn	mgKOH/g	1.8	ASTM D2896	1.8 mgKOH/g ASTM D2896
Approvals		Allison C-4, Allison TES-389, Caterpillar TO-2, DTFR 13C100 (MB 236.1), DTFR 13C170 (MB 236.9), Ford MERCON®, GM Dexron® II E, GM Dexron® III F, GM Dexron® III H, MAN 339 L1, MAN 339 Type V1, MAN 339 Type Z1, MAN 339 Type Z2, MB 236.1, MB 236.10, MB 236.5, MB 236.6, MB 236.9, Voith H55.6336.3x Extended Drain (G1363), Volvo 97341, ZF TE-ML 02F, ZF TE-ML 03D, ZF TE-ML 04D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 14B, ZF TE-ML 16L, ZF TE-ML 16R, ZF TE-ML 17C, ZF TE-ML 20B, ZF TE-ML 25B		Allison C-4, Allison TES-389, Caterpillar TO-2, DTFR 13C100 (MB 236.1), DTFR 13C170 (MB 236.9), Ford MERCON®, GM Dexron® II E, GM Dexron® III F, GM Dexron® III H, MAN 339 L1, MAN 339 Type V1, MAN 339 Type Z1, MAN 339 Type Z2, MB 236.1, MB 236.10, MB 236.5, MB 236.6, MB 236.9, Voith H55.6336.3x Extended Drain (G1363), Volvo 97341, ZF TE-ML 02F, ZF TE-ML 03D, ZF TE-ML 04D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 14B, ZF TE-ML 16L, ZF TE-ML 16R, ZF TE-ML 17C, ZF TE-ML 20B, ZF TE-ML 25B

Power steering ZF Servocom

Liquid volume (basic): 7 L

ATF Dexron II E

Transmission fluid

Application NoteRAVENOL ATF Dexron II E is developed for use in automatic transmission and torque converter transmission and power shift transmission with required specification.

Manufacturer Approved:
Allison C-4, MB-Approval 236.8, Voith H55.6336.3x Extended Drain (G1363)

Compliance with the requirements:
Caterpillar TO-2, DTFR 13C150 (MB 236.8), MAN 339 Type V2, MAN 339 Type Z2, MB 236.5, ZF TE-ML 04D, ZF TE-ML 09X, ZF TE-ML 14B, ZF TE-ML 16L

show details

Equivalents OEM:
Alpine 0100641, Alpine 0100642, Alpine 0100643, Alpine 0100644, Alpine 0100645, Alpine 100641, Alpine 100642, Alpine 100643, Alpine 100644, Alpine 100645, Alpine 100645, Land Rover STC8261

Usage mode: normal

Available packaging
Full description
Product parameters

Volume:
1 L

vendor code:
1211103-001

Code:
4014835732612

Volume:
4 L

vendor code:
1211103-004

Code:
4014835732698

Volume:
10 L

vendor code:
1211103-010

Code:
4014835732643

Volume:
20 L

vendor code:
1211103-020

Volume:
20 L, ecobox

vendor code:
1211103-B20

Volume:
60 L

vendor code:
1211103-060

Volume:
60 L, print

vendor code:
1211103-D60

Code:
4014835732636

Volume:
208 L

vendor code:
1211103-208

Volume:
208 L, print

vendor code:
1211103-D28

Volume:
1000 L

vendor code:
1211103-700

Application Note

RAVENOL ATF Dexron II E is developed for use in automatic transmission and torque converter transmission and power shift transmission with required specification.

RAVENOL ATF Dexron II E is recommended if ATF Type Dexron II E is to be used according to manufacturer’s specification.

Characteristics

reliable protection against wear, sludge, adhesion and corrosion
a very shear stable viscosity-temperature behaviour
can be used both at very low and very high temperatures
an extremely high thermal load
no foaming, even under the heaviest loads
compatibility with sealing materials

Parameter	Unit	Value	Audit
ATF		Dexron II E		Dexron II E
Recommendations		Caterpillar TO-2, DTFR 13C150 (MB 236.8), MAN 339 V2, MAN 339 Z2, MB 236.5, ZF TE-ML 04D, ZF TE-ML 09X, ZF TE-ML 14B, ZF TE-ML 16L		Caterpillar TO-2, DTFR 13C150 (MB 236.8), MAN 339 V2, MAN 339 Z2, MB 236.5, ZF TE-ML 04D, ZF TE-ML 09X, ZF TE-ML 14B, ZF TE-ML 16L
Brand		RAVENOL		RAVENOL
Type		Synthetic		Synthetic
Manufacturer Approved		Allison C-4, MB-Approval 236.8, Voith H55.6336.3x Extended Drain (G1363)		Allison C-4, MB-Approval 236.8, Voith H55.6336.3x Extended Drain (G1363)
Recomendations		Caterpillar TO-2, DTFR 13C150 (MB 236.8), MAN 339 Type V2, MAN 339 Type Z2, MB 236.5, ZF TE-ML 04D, ZF TE-ML 09X, ZF TE-ML 14B, ZF TE-ML 16L		Caterpillar TO-2, DTFR 13C150 (MB 236.8), MAN 339 Type V2, MAN 339 Type Z2, MB 236.5, ZF TE-ML 04D, ZF TE-ML 09X, ZF TE-ML 14B, ZF TE-ML 16L
specification		Ford MERCON®, GM Dexron® II E		Ford MERCON®, GM Dexron® II E
Density at 20 °C	g/cm³	834	EN ISO 12185	834 g/cm³ EN ISO 12185
Color		Red	visual	Red visual
Viscosity at 100 °C	mm²/s	7.5	DIN 51562-1	7.5 mm²/s DIN 51562-1
Viscosity at 40 °C	mm²/s	32	DIN 51562-1	32 mm²/s DIN 51562-1
Viscosity at -40 °C	mPa*s	8.3	ASTM D2983	8.3 mPa*s ASTM D2983
Viscosity Index VI		191	DIN ISO 2909	191 DIN ISO 2909
Pourpoint	°C	-57	DIN ISO 3016	-57 °C DIN ISO 3016
Flashpoint	°C	226	DIN EN ISO 2592	226 °C DIN EN ISO 2592
tbn	mgKOH/g	1.7	ASTM D2896	1.7 mgKOH/g ASTM D2896
Approvals		Allison C-4, Caterpillar TO-2, DTFR 13C150 (MB 236.8), Ford MERCON®, GM Dexron® II E, MAN 339 Type V2, MAN 339 Type Z2, MB 236.5, MB 236.8, Voith H55.6336.3x Extended Drain (G1363), ZF TE-ML 04D, ZF TE-ML 09X, ZF TE-ML 14B, ZF TE-ML 16L		Allison C-4, Caterpillar TO-2, DTFR 13C150 (MB 236.8), Ford MERCON®, GM Dexron® II E, MAN 339 Type V2, MAN 339 Type Z2, MB 236.5, MB 236.8, Voith H55.6336.3x Extended Drain (G1363), ZF TE-ML 04D, ZF TE-ML 09X, ZF TE-ML 14B, ZF TE-ML 16L

ATF Dexron III H

For automatic transmission

RAVENOL ATF DEXRON III H is universal ATF (Automatic Transmission Fluid) for all automatic transmission with and without controlled torque converter lockup clutch (so-called GKÜB = gear-clutch-lock) which are required for the transmission fluid type Dexron III H.

Manufacturer Approved:
Allison C-4, Allison TES-389, Voith H55.6336.3x Extended Drain (G1363), ZF TE-ML 04D, ZF TE-ML 14B, ZF TE-ML 20B, ZF TE-ML 25B

Compliance with the requirements:
Caterpillar TO-2, DTFR 13C100 (MB 236.1), DTFR 13C170 (MB 236.9), Ford MERCON®, MAN 339 L1, MAN 339 Type V1, MAN 339 Type Z1, MAN 339 Type Z2, MB 236.1, MB 236.5, MB 236.6, MB 236.9, MB 236.10, Volvo 97341, ZF TE-ML 02F, ZF TE-ML 03D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 16L, ZF TE-ML 16R, ZF TE-ML 17C

show details

Usage mode: normal

Available packaging
Full description
Product parameters

Volume:
1 L

vendor code:
1212100-001

Code:
4014835732810

Volume:
4 L

vendor code:
1212100-004

Code:
4014835732896

Volume:
10 L

vendor code:
1212100-010

Code:
4014835732841

Volume:
20 L

vendor code:
1212100-020

Code:
4014835732827

Volume:
20 L, ecobox

vendor code:
1212100-B20

Code:
4014835787025

Volume:
60 L

vendor code:
1212100-060

Code:
4014835732865

Volume:
60 L, print

vendor code:
1212100-D60

Code:
4014835732834

Volume:
208 L

vendor code:
1212100-208

Code:
4014835732889

Volume:
208 L, print

vendor code:
1212100-D28

Code:
4014835732803

Volume:
1000 L

vendor code:
1212100-700

RAVENOL ATF DEXRON III H is universal ATF (Automatic Transmission Fluid) for all automatic transmission with and without controlled torque converter lockup clutch (so-called GKÜB = gear-clutch-lock) which are required for the transmission fluid type Dexron III H.

Application Note

RAVENOL ATF DEXRON III H was developed for use in automatic transmissions with electronically controlled converter lockup clutch.

RAVENOL ATF DEXRON III H is especially suitable for use in transmissions with ATF Dexron III H specification.

RAVENOL ATF DEXRON III H is backwards compatible and can be used in transmissions with specification ATF Dexron F III.

RAVENOL ATF DEXRON III H is mixable with all ATF brands. It is advised to rinse with RAVENOL ATF DEXRON III H before, beforehand the final filling with RAVENOL ATF DEXRON III H is made.

Characteristics

Very good lubricating properties even at low temperatures in winter
High and stable viscosity index
Very low flow point
Excellent oxidation stability
Extensive protection against wear, corrosion and foaming
Well-tuned friction properties
Neutral behaviour towards sealing materials
Neutral behaviour by inhibition towards non-ferrous metals

Parameter	Unit	Value	Audit
ATF		Dexron III H		Dexron III H
Recommendations		Caterpillar TO-2, DTFR 13C100 (MB 236.1), DTFR 13C170 (MB 236.9), Ford MERCON® M-940717, MAN 339 L1, MAN 339 V1, MAN 339 Z1, MAN 339 Z2, MB 236.1, MB 236.10, MB 236.5, MB 236.6, MB 236.9, Nissan, Volvo 1161521, Volvo 1161621, VOLVO Transmission Oil 97341, ZF TE-ML 02F, ZF TE-ML 03D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 16L, ZF TE-ML 16R, ZF TE-ML 17C		Caterpillar TO-2, DTFR 13C100 (MB 236.1), DTFR 13C170 (MB 236.9), Ford MERCON® M-940717, MAN 339 L1, MAN 339 V1, MAN 339 Z1, MAN 339 Z2, MB 236.1, MB 236.10, MB 236.5, MB 236.6, MB 236.9, Nissan, Volvo 1161521, Volvo 1161621, VOLVO Transmission Oil 97341, ZF TE-ML 02F, ZF TE-ML 03D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 16L, ZF TE-ML 16R, ZF TE-ML 17C
Brand		RAVENOL		RAVENOL
Type		Synthetic		Synthetic
Manufacturer Approved		Allison C-4, Allison TES-389, Voith H55.6336.3x Extended Drain (G1363), ZF TE-ML 04D, ZF TE-ML 14B, ZF TE-ML 20B, ZF TE-ML 25B		Allison C-4, Allison TES-389, Voith H55.6336.3x Extended Drain (G1363), ZF TE-ML 04D, ZF TE-ML 14B, ZF TE-ML 20B, ZF TE-ML 25B
Recomendations		Caterpillar TO-2, DTFR 13C100 (MB 236.1), DTFR 13C170 (MB 236.9), Ford MERCON®, MAN 339 L1, MAN 339 Type V1, MAN 339 Type Z1, MAN 339 Type Z2, MB 236.1, MB 236.10, MB 236.5, MB 236.6, MB 236.9, Volvo 97341, ZF TE-ML 02F, ZF TE-ML 03D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 16L, ZF TE-ML 16R, ZF TE-ML 17C		Caterpillar TO-2, DTFR 13C100 (MB 236.1), DTFR 13C170 (MB 236.9), Ford MERCON®, MAN 339 L1, MAN 339 Type V1, MAN 339 Type Z1, MAN 339 Type Z2, MB 236.1, MB 236.10, MB 236.5, MB 236.6, MB 236.9, Volvo 97341, ZF TE-ML 02F, ZF TE-ML 03D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 16L, ZF TE-ML 16R, ZF TE-ML 17C
specification		Allison C-4, Allison TES-389, GM Dexron® II E, GM DEXRON® III F, GM Dexron® III H		Allison C-4, Allison TES-389, GM Dexron® II E, GM DEXRON® III F, GM Dexron® III H
Suitable for		Nissan		Nissan
Compliant products		Volvo 1161521, Volvo 1161621		Volvo 1161521, Volvo 1161621
Density at 20 °C	g/cm³	847	EN ISO 12185	847 g/cm³ EN ISO 12185
Color		Red	visual	Red visual
Viscosity at 100 °C	mm²/s	7.2	DIN 51562-1	7.2 mm²/s DIN 51562-1
Viscosity at 40 °C	mm²/s	33.9	DIN 51562-1	33.9 mm²/s DIN 51562-1
Viscosity Index VI		185	DIN ISO 2909	185 DIN ISO 2909
Brookfield Viscosity at -40 °C	mPa*s	14.200	ASTM D2983	14.200 mPa*s ASTM D2983
Pourpoint	°C	-51	DIN ISO 3016	-51 °C DIN ISO 3016
Flashpoint	°C	210	DIN EN ISO 2592	210 °C DIN EN ISO 2592
Seq. I at 24 °C	ml/ml	0/0	ASTM D892	0/0 ml/ml ASTM D892
Seq. II at 93,5 °C	ml/ml	0/0	ASTM D892	0/0 ml/ml ASTM D892
Seq. III at 24 °C after 93,5 °C	ml/ml	0/0	ASTM D892	0/0 ml/ml ASTM D892
Copper Strip Test at 121 °C		1b	ASTM D130	1b ASTM D130
tbn	mgKOH/g	1.8	ASTM D2896	1.8 mgKOH/g ASTM D2896
Approvals		Allison C-4, Allison TES-389, Caterpillar TO-2, DTFR 13C100 (MB 236.1), DTFR 13C170 (MB 236.9), Ford MERCON®, GM Dexron® II E, GM Dexron® III F, GM Dexron® III H, MAN 339 L1, MAN 339 Type V1, MAN 339 Type Z1, MAN 339 Type Z2, MB 236.1, MB 236.10, MB 236.5, MB 236.6, MB 236.9, Voith H55.6336.3x Extended Drain (G1363), Volvo 97341, ZF TE-ML 02F, ZF TE-ML 03D, ZF TE-ML 04D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 14B, ZF TE-ML 16L, ZF TE-ML 16R, ZF TE-ML 17C, ZF TE-ML 20B, ZF TE-ML 25B		Allison C-4, Allison TES-389, Caterpillar TO-2, DTFR 13C100 (MB 236.1), DTFR 13C170 (MB 236.9), Ford MERCON®, GM Dexron® II E, GM Dexron® III F, GM Dexron® III H, MAN 339 L1, MAN 339 Type V1, MAN 339 Type Z1, MAN 339 Type Z2, MB 236.1, MB 236.10, MB 236.5, MB 236.6, MB 236.9, Voith H55.6336.3x Extended Drain (G1363), Volvo 97341, ZF TE-ML 02F, ZF TE-ML 03D, ZF TE-ML 04D, ZF TE-ML 05L, ZF TE-ML 14A, ZF TE-ML 14B, ZF TE-ML 16L, ZF TE-ML 16R, ZF TE-ML 17C, ZF TE-ML 20B, ZF TE-ML 25B

Hydraulic clutch system, coupling + gear shift (Kongsberg)

E-PSF Fluid

For power steering

RAVENOL E- PSF Fluid is guaranteeing an optimized power transmission.

Compliance with the requirements:
Fiat 9.55550-AG3, JTEKT EHPS, JTEKT EHS, MAN M3289, Nissan E-PSF, PSA S71 2710, Renault PSF Class 1, Toyota PSF-EH

show details

Equivalents OEM:
Chrysler 68068618AA, Chrysler 68088485AA, Chrysler 68088485AB, Chrysler 68088485GA, Chrysler 68088485GB, Chrysler 68088485LB, Citroen 333263012255, Nissan 999MPEPSF00P, Nissan KLF3000001, Nissan KLF3000004, Nissan KLF5100001, Nissan KLF5100001EU, Nissan KLF300000101, Nissan KLF300000401, PSA 9730A5, PSA 9979A3, PSA 1615099680, PSA 1615099680, Toyota 0888601206, Toyota 0888681250, Toyota SU001A2832, Toyota SU001A4824

Usage mode: normal

Available packaging
Full description
Product parameters

Volume:
1 L

vendor code:
1181002-001

Code:
4014835839908

RAVENOL E- PSF Fluid is guaranteeing an optimized power transmission.

RAVENOL E- PSF Fluid is designed on the basis of particularly high quality base oils with special additives and inhibition which ensures the proper functioning of the electro-hydraulic power steering system.

Application Note

RAVENOL E- PSF Fluid is especially developed for the use in electro-hydraulic power steering systems of Nissan and Toyota (JTEKT EHS Elektro-Hydraulik Servolenkung/EHPS Electro-Hydraulic Power Steering).

RAVENOL E- PSF Fluid is also suitable for the hydropneumatic Hydractive III und Hydractive III+ suspension of Citroën.

Characteristics

A very low pour point
An excellent foam prevention, no foam formation
A good lubricating ability even at low temperatures in winter
A high and stable viscosity index
A very good oxidation stability
Excellent protection against wear and tear, corrosion and foam formation
Well-tuned friction characteristics
Neutral behaviour against sealing materials
Neutral behaviour because of inhibition against non-ferrous metals

Parameter	Unit	Value	Audit
Recommendations		Citroën DA 9730 A5, Citroën LDS 9979 A3, Fiat 9.55550-AG3, JTEKT EHS/ EHPS, MAN M 3289, Nissan 999MP-EPSF00P, Nissan E-PSF, Nissan KLF51-00001, PSA S71 2710, Renault PSF Klasse 1 (Renault Laguna III), Toyota 08886-01206, Toyota PSF-EH		Citroën DA 9730 A5, Citroën LDS 9979 A3, Fiat 9.55550-AG3, JTEKT EHS/ EHPS, MAN M 3289, Nissan 999MP-EPSF00P, Nissan E-PSF, Nissan KLF51-00001, PSA S71 2710, Renault PSF Klasse 1 (Renault Laguna III), Toyota 08886-01206, Toyota PSF-EH
Brand		RAVENOL		RAVENOL
Type		Full synthetic		Full synthetic
Recomendations		Fiat 9.55550-AG3, JTEKT EHPS, JTEKT EHS, MAN M3289, Nissan E-PSF, PSA S71 2710, Renault PSF Class 1, Toyota PSF-EH		Fiat 9.55550-AG3, JTEKT EHPS, JTEKT EHS, MAN M3289, Nissan E-PSF, PSA S71 2710, Renault PSF Class 1, Toyota PSF-EH
Suitable for		PSA DA, PSA LSD		PSA DA, PSA LSD
Compliant products		Nissan 999MP-EPSF00P, Nissan KLF51-00001, PSA 9730.A5, PSA 9979.A3, Toyota 08886-01206		Nissan 999MP-EPSF00P, Nissan KLF51-00001, PSA 9730.A5, PSA 9979.A3, Toyota 08886-01206
Density at 20 °C	g/cm³	821	EN ISO 12185	821 g/cm³ EN ISO 12185
Color		Colorless	visual	Colorless visual
Viscosity at 100 °C	mm²/s	6.1	DIN 51562-1	6.1 mm²/s DIN 51562-1
Viscosity at 40 °C	mm²/s	19	DIN 51562-1	19 mm²/s DIN 51562-1
Viscosity at -40 °C	mm²/s	960	ASTM D445	960 mm²/s ASTM D445
Viscosity Index VI		312	DIN ISO 2909	312 DIN ISO 2909
Brookfield Viscosity at -40 °C	mPa*s	900	ASTM D2983	900 mPa*s ASTM D2983
Pourpoint	°C	-75	DIN ISO 3016	-75 °C DIN ISO 3016
Flashpoint	°C	154	DIN EN ISO 2592	154 °C DIN EN ISO 2592
Approvals		Fiat 9.55550-AG3, JTEKT EHPS, JTEKT EHS, MAN M 3289, Nissan E-PSF, PSA S71 2710, Renault PSF Class 1, Toyota PSF-EH		Fiat 9.55550-AG3, JTEKT EHPS, JTEKT EHS, MAN M 3289, Nissan E-PSF, PSA S71 2710, Renault PSF Class 1, Toyota PSF-EH

Hydraulic system of throw-back cab

Hydraulikol TSX 15 (HVPL)

Hydraulic oil

Application NoteRAVENOL Hydraulikoel TSX 15 (HVLP) is suitable for heavy loaded hydraulic machines of the industry, for earth moving machines and agricultural machines. Preferred use in case of great variations of the operation temperature. No use in case of silver and/or silver-coated components in the hydraulic machines.

Compliance with the requirements:
AFNOR NFE 48-603 HV, AFNOR NFE 48-690/1, Bosch Rexroth RE 90220, Cetop RP 91H HV, GB 111118.1 L-HV, ISO 11158 HV, SAE MS 1004, Sauer-Danfoss 520L0463

show details

SAE: 15

Equivalents OEM:
Scania 2252143

Available packaging
Full description
Product parameters

Volume:
20 L

vendor code:
-

Volume:
20 L, ecobox

vendor code:
1323202-B20

Volume:
60 L

vendor code:
1323202-060

Code:
4014835759961

Volume:
208 L

vendor code:
1323202-208

Code:
4014835759985

Volume:
1000 L

vendor code:
1323202-700

Volume:
20 L

vendor code:
1323202-020

Volume:
1 L

vendor code:
1323202-001

Volume:
5 L

vendor code:
1323202-005

Application Note

RAVENOL Hydraulikoel TSX 15 (HVLP) is suitable for heavy loaded hydraulic machines of the industry, for earth moving machines and agricultural machines. Preferred use in case of great variations of the operation temperature. No use in case of silver and/or silver-coated components in the hydraulic machines.

Characteristics

A high and stable viscosity index
An excellent corrosion protection
An excellent protection against wear
A very good air and water separation behaviour to prevent foam formation
Neutral behaviour towards sealing of plastics
A very low pour point

Parameter	Unit	Value	Audit
Recommendations		AFNOR NFE 48-603 HV, AFNOR NFE 48-690/1, Bosch Rexroth RE 90220, CETOP RP 91H HV, GB 111118.1 L-HV, ISO 11158 HV, SAE MS1004, Sauer-Danfoss 520L0463		AFNOR NFE 48-603 HV, AFNOR NFE 48-690/1, Bosch Rexroth RE 90220, CETOP RP 91H HV, GB 111118.1 L-HV, ISO 11158 HV, SAE MS1004, Sauer-Danfoss 520L0463
Brand		RAVENOL		RAVENOL
SAE		15		15
Type		Mineral		Mineral
Recomendations		AFNOR NFE 48-603 HV, AFNOR NFE 48-690/1, Bosch Rexroth RE 90220, Cetop RP 91H HV, GB 111118.1 L-HV, ISO 11158 HV, SAE MS 1004, Sauer-Danfoss 520L0463		AFNOR NFE 48-603 HV, AFNOR NFE 48-690/1, Bosch Rexroth RE 90220, Cetop RP 91H HV, GB 111118.1 L-HV, ISO 11158 HV, SAE MS 1004, Sauer-Danfoss 520L0463
specification		DIN 51524-3, ISO 6743-4 HV		DIN 51524-3, ISO 6743-4 HV
Density at 20 °C	g/cm³	839.2	EN ISO 12185	839.2 g/cm³ EN ISO 12185
Color		Yellow	visual	Yellow visual
Viscosity at 100 °C	mm²/s	3.9	DIN 51562-1	3.9 mm²/s DIN 51562-1
Viscosity at 40 °C	mm²/s	15.1	DIN 51562-1	15.1 mm²/s DIN 51562-1
Viscosity Index VI		166	DIN ISO 2909	166 DIN ISO 2909
Pourpoint	°C	-42	DIN ISO 3016	-42 °C DIN ISO 3016
Flashpoint	°C	180	DIN EN ISO 2592	180 °C DIN EN ISO 2592
Approvals		AFNOR NFE 48-603 HV, AFNOR NFE 48-690/1, Bosch Rexroth RE 90220, Cetop RP 91H HV, DIN 51524-3, GB 111118.1 L-HV, ISO 11158 HV, ISO 6743-4 HV, SAE MS 1004, Sauer-Danfoss 520L0463		AFNOR NFE 48-603 HV, AFNOR NFE 48-690/1, Bosch Rexroth RE 90220, Cetop RP 91H HV, DIN 51524-3, GB 111118.1 L-HV, ISO 11158 HV, ISO 6743-4 HV, SAE MS 1004, Sauer-Danfoss 520L0463

Wheel bearings rear

Liquid volume (basic): 120 G

Mehrzweckfett mit Graphit

For lubrication

RAVENOL Mehrzweckfett mit Graphit is formulated with a highly refined base oil mixture which contains less than 3% polycyclic aromatics.Through the graphite at high temperatures a lubrication film on the metals is formed, and the graphite takes lubrication to achieve optimal results.

show details

Equivalents OEM:
VAG G060735A2

Available packaging
Full description
Product parameters

Volume:
100 g

vendor code:
1340102-100

Code:
4014835844391

Volume:
200 g

vendor code:
1340102-200

Volume:
400 g

vendor code:
1340102-400

Code:
4014835768147

Volume:
1 kg

vendor code:
1340102-001

Code:
4014835200210

Volume:
5 kg

vendor code:
1340102-005

Code:
4014835200265

Volume:
10 kg

vendor code:
1340102-010

Code:
4014835200227

Volume:
15 kg

vendor code:
1340102-015

Volume:
25 kg

vendor code:
1340102-025

Code:
4014835200258

Volume:
180 kg

vendor code:
1340102-180

Code:
4014835200272

RAVENOL Mehrzweckfett mit Graphit is formulated with a highly refined base oil mixture which contains less than 3% polycyclic aromatics.Through the graphite at high temperatures a lubrication film on the metals is formed, and the graphite takes lubrication to achieve optimal results.

The optimized formulation of RAVENOL Mehrzweckfett mit Graphit can also capture temperature peaks in the application.

Application Note

RAVENOL Mehrzweckfett mit Graphit has been designed for applications exposed to high temperatures and shock loads.

RAVENOL Mehrzweckfett mit Graphit is used in oven conveyor belts, pistons in hydraulic pumps and all types of bearings that run at low speeds.

RAVENOL Mehrzweckfett mit Graphit is also used as a sealant in high temperature gaskets from steam pipes and other hot pipe connections.

Characteristics

Extreme shear stability
Excellent corrosion protection
Very good mechanical and chemical stability
Very good aging resistant
Good pump output also at low temperatures

Parameter	Unit	Value	Audit
Brand		RAVENOL		RAVENOL
specification		DIN 51502 KPF2K-30, ISO I6743-9: ISO-L-XCCFB2		DIN 51502 KPF2K-30, ISO I6743-9: ISO-L-XCCFB2
Color		Black gray	visual	Black gray visual
Thickener		lithium soap	DIN 51757	lithium soap DIN 51757
Additives		graphite	DIN 51757	graphite DIN 51757
NLGI-Class		2	DIN 51818	2 DIN 51818
Product Classification		KPF2K-30	DIN 51502	KPF2K-30 DIN 51502
Working Temperature	°C	-30 / +120	DIN 51825	-30 / +120 °C DIN 51825
Short term temperature up to	°C	130	DIN 51757	130 °C DIN 51757
Worked Penetration at 60 Strokes		265-295	ISO 2137	265-295 ISO 2137
Corrosion (SKF Emcor dist. Water)		1	DIN 51802	1 DIN 51802
Dropping Point	°C	180 —	DIN ISO 2176	180 — °C DIN ISO 2176
Copper Corrosion (24h/120 °C)		1	DIN 51811	1 DIN 51811
Water Resistance (3h/90 °C)	°C	1-90	DIN 51807-1	1-90 °C DIN 51807-1
VKA Pressure Carrying Capacity	N	2000 — 2200	DIN 51350-4	2000 — 2200 N DIN 51350-4
Kinematic Viscosity (Base Oil) at 40 °C	mm²/s	80	DIN 51562-1	80 mm²/s DIN 51562-1
Approvals		DIN 51502 KPF2K-30, ISO I6743-9: ISO-L-XCCFB2		DIN 51502 KPF2K-30, ISO I6743-9: ISO-L-XCCFB2

Mehrzweckfett OML

For lubrication

RAVENOL Mehrzweckfett OML has an extreme mechanical stability and a very low friction value. Therefore it can be transported easily.

show details

Equivalents OEM:
Alpine 0101001, Alpine 0101002, Alpine 0101003, Alpine 0101004, Alpine 0101005, Alpine 0101005

Available packaging
Full description
Product parameters

Volume:
100 g

vendor code:
1340101-100

Code:
4014835844339

Volume:
200 g

vendor code:
1340101-200

Volume:
400 g

vendor code:
1340101-400

Code:
4014835768048

Volume:
5 kg

vendor code:
1340101-005

Code:
4014835200159

Volume:
10 kg

vendor code:
1340101-010

Code:
4014835200111

Volume:
15 kg

vendor code:
1340101-015

Volume:
25 kg

vendor code:
1340101-025

Code:
4014835200128

Volume:
180 kg

vendor code:
1340101-180

Code:
4014835200142

RAVENOL Mehrzweckfett OML has an extreme mechanical stability and a very low friction value. Therefore it can be transported easily.

Application Note

RAVENOL Mehrzweckfett OML is used for the lubrication of easy loaded antifriction bearings and machine components. It is also suited as multipurpose lubrication grease for vehicles.

Characteristics

Universal use, multipurpose characteristic for a mixed car pool
Extreme shear stability
Excellent corrosion protection
Excellent wear protection
Very good mechanical and chemical stability
Very good aging resistant
Good pumpability, even at low temperatures

Parameter	Unit	Value	Audit
Brand		RAVENOL		RAVENOL
specification		DIN 51502 K2K-30, ISO 6743-9: ISO-L-XCCEA2		DIN 51502 K2K-30, ISO 6743-9: ISO-L-XCCEA2
Color		Light brown	visual	Light brown visual
Thickener		lithium soap	DIN 51757	lithium soap DIN 51757
NLGI-Class		2	DIN 51818	2 DIN 51818
Product Classification		K2K-30	DIN 51502	K2K-30 DIN 51502
Working Temperature	°C	-30 / +120	DIN 51825	-30 / +120 °C DIN 51825
Short term temperature up to	°C	130	DIN 51757	130 °C DIN 51757
Worked Penetration at 60 Strokes		265-295	ISO 2137	265-295 ISO 2137
Corrosion (SKF Emcor dist. Water)		1	DIN 51802	1 DIN 51802
Dropping Point	°C	180 —	DIN ISO 2176	180 — °C DIN ISO 2176
Copper Corrosion (24h/120 °C)		1	DIN 51811	1 DIN 51811
Water Resistance (3h/90 °C)	°C	1-90	DIN 51807-1	1-90 °C DIN 51807-1
VKA Pressure Carrying Capacity	N	2000 — 2200	DIN 51350-4	2000 — 2200 N DIN 51350-4
Kinematic Viscosity (Base Oil) at 40 °C	mm²/s	130	DIN 51562-1	130 mm²/s DIN 51562-1
Approvals		DIN 51502 K2K-30, ISO 6743-9: ISO-L-XCCEA2		DIN 51502 K2K-30, ISO 6743-9: ISO-L-XCCEA2

Mehrzweckfett mit MoS2

For CV joint

RAVENOL Mehrzweckfett mit MoS2 is formulated with a highly refined base oil mixture which contains less than 3% polycyclic aromatics.

show details

Equivalents OEM:
Alpine 0101061, Alpine 0101062, Alpine 0101063, Alpine 0101064, Alpine 0101065, Alpine 0101066, BMW 83230417754, FEBI 02582, FEBI 02597, FEBI 2582, FEBI 2597, Ford 1019761, Ford 1720193, Hyundai Motor 4959022B00A, MB A001989035112, Polaris 2871515, Polaris 2871551, Polaris 2871551, SWAG 99830001, VAG G052172A2, VAG G052723A2, Yamalube ACCMOLDMGS10

Available packaging
Full description
Product parameters

Volume:
100 g

vendor code:
1340103-100

Code:
4014835844452

Volume:
200 g

vendor code:
1340103-200

Volume:
400 g

vendor code:
1340103-400

Code:
4014835768246

Volume:
1 kg

vendor code:
1340103-001

Code:
4014835200333

Volume:
5 kg

vendor code:
1340103-005

Code:
4014835200357

Volume:
10 kg

vendor code:
1340103-010

Code:
4014835200319

Volume:
15 kg

vendor code:
1340103-015

Volume:
25 kg

vendor code:
1340103-025

Code:
4014835200326

Volume:
180 kg

vendor code:
1340103-180

Code:
4014835200371

RAVENOL Mehrzweckfett mit MoS2 is formulated with a highly refined base oil mixture which contains less than 3% polycyclic aromatics.

The optimized formulation of RAVENOL Mehrzweckfett mit MoS2 has distinctive friction-reducing properties and so-called dry running properties.

Application Note

RAVENOL Mehrzweckfett mit MoS2 has been designed for applications exposed to extreme pressure and shock loaded bearings with relatively slow sliding movements.

RAVENOL Mehrzweckfett mit MoS2 is recommended for friction and roller bearings of all types during aggravated operating conditions.

RAVENOL Mehrzweckfett mit MoS2 is also used for chassis lubricating.

Characteristics

Extreme shear stability
Excellent corrosion protection
Very good mechanical and chemical stability
Very good aging resistant
Good pump output also at low temperatures

Parameter	Unit	Value	Audit
Brand		RAVENOL		RAVENOL
specification		DIN 51502 KPF2K-30, ISO 6743-9: ISO-L-XCCIB2		DIN 51502 KPF2K-30, ISO 6743-9: ISO-L-XCCIB2
Color		Black gray	visual	Black gray visual
Thickener		lithium soap	DIN 51757	lithium soap DIN 51757
Additives		molybdenum disulfide	DIN 51757	molybdenum disulfide DIN 51757
NLGI-Class		2	DIN 51818	2 DIN 51818
Product Classification		KPF2K-30	DIN 51502	KPF2K-30 DIN 51502
Working Temperature	°C	-30 / +120	DIN 51825	-30 / +120 °C DIN 51825
Short term temperature up to	°C	130	DIN 51757	130 °C DIN 51757
Worked Penetration at 60 Strokes		265-295	ISO 2137	265-295 ISO 2137
Corrosion (SKF Emcor dist. Water)		1	DIN 51802	1 DIN 51802
Dropping Point	°C	180 —	DIN ISO 2176	180 — °C DIN ISO 2176
Copper Corrosion (24h/120 °C)		1	DIN 51811	1 DIN 51811
Water Resistance (3h/90 °C)	°C	1-90	DIN 51807-1	1-90 °C DIN 51807-1
VKA Pressure Carrying Capacity	N	2800 — 3000	DIN 51350-4	2800 — 3000 N DIN 51350-4
Kinematic Viscosity (Base Oil) at 40 °C	mm²/s	80	DIN 51562-1	80 mm²/s DIN 51562-1
Approvals		DIN 51502 KPF2K-30, ISO 6743-9: ISO-L-XCCIB2		DIN 51502 KPF2K-30, ISO 6743-9: ISO-L-XCCIB2

Central lubrication system oil Vogel

EURO IV Truck 10W-40

For mixed park

RAVENOL EURO IV Truck SAE 10W-40 is UHPD-Motoroil (Ultra High Performance Diesel) with special requirements for Diesel Particular Filters DPF for the LOW SPAsh Technology. Offers low content of sulphur, phosphor and low ash content.

Manufacturer Approved:
Deutz DQC IV-10 LA, DTFR 15C110, Mack EO-N, Renault RLD-2, Tatra TDS 30/12, Volvo VDS-3

Compliance with the requirements:
DAF HP-2, MAN M 3277, MAN M 3477, MB 228.51, MTU Type 3, MTU Type 3.1, Renault RXD, Scania LDF

show details

SAE: 10W-40

API: CI-4

ACEA: E6, E7

Available packaging
Full description
Product parameters

Volume:
1 L

vendor code:
1122107-001

Volume:
5 L

vendor code:
1122107-005

Code:
4014835725959

Volume:
10 L

vendor code:
1122107-010

Code:
4014835725942

Volume:
20 L

vendor code:
1122107-020

Code:
4014835725928

Volume:
20 L, ecobox

vendor code:
1122107-B20

Volume:
60 L

vendor code:
1122107-060

Code:
4014835725966

Volume:
60 L, print

vendor code:
1122107-D60

Code:
4014835725935

Volume:
208 L

vendor code:
1122107-208

Code:
4014835725980

Volume:
208 L, print

vendor code:
1122107-D28

Code:
4014835725904

Volume:
1000 L

vendor code:
1122107-700

RAVENOL EURO IV Truck SAE 10W-40 is UHPD-Motoroil (Ultra High Performance Diesel) with special requirements for Diesel Particular Filters DPF for the LOW SPAsh Technology. Offers low content of sulphur, phosphor and low ash content.

Application Note

RAVENOL EURO IV Truck SAE 10W-40 is maximum efficiency engine oil which can be used the whole year and which was produced for the new exhaust gas emission directives respectively for vehicles with exhaust gas return systems.

RAVENOL EURO IV Truck SAE 10W-40 can be used in all diesel engines with and without turbo charging. Suitable for EURO I, II, III, IV and EURO V engines.

Characteristics

High corrosion protection
An excellent oxidation stability
An excellent high temperature stability
Excellent detergent and dispersant characteristics
Profitability because of a low fuel consumption
Long endurance because of a high oxidation stability
An excellent cold start behaviour, a quick engine lubrication at low temperatures
A very good viscosity temperature behaviour
Neutrality of sealing

Parameter	Unit	Value	Audit
Recommendations		DAF HP-2, MAN M 3277 (CRF Abgasrückführung), MAN M 3477, MB 228.51, MTU Typ 3, MTU Typ 3.1, Renault RXD, Scania LDF		DAF HP-2, MAN M 3277 (CRF Abgasrückführung), MAN M 3477, MB 228.51, MTU Typ 3, MTU Typ 3.1, Renault RXD, Scania LDF
SAE		10W-40		10W-40
Brand		RAVENOL		RAVENOL
Type		Semi-synthetic		Semi-synthetic
API		CI-4		CI-4
ACEA		E6, E7		E6, E7
Manufacturer Approved		Deutz DQC IV-10 LA, DTFR 15C110, Mack EO-N, Renault RLD-2, Tatra TDS 30/12, Volvo VDS-3		Deutz DQC IV-10 LA, DTFR 15C110, Mack EO-N, Renault RLD-2, Tatra TDS 30/12, Volvo VDS-3
Recomendations		DAF HP-2, MAN M 3277, MAN M 3477, MB 228.51, MTU Type 3, MTU Type 3.1, Renault RXD, Scania LDF		DAF HP-2, MAN M 3277, MAN M 3477, MB 228.51, MTU Type 3, MTU Type 3.1, Renault RXD, Scania LDF
Density at 20 °C	g/cm³	856	EN ISO 12185	856 g/cm³ EN ISO 12185
Color		Brown	visual	Brown visual
Viscosity at 100 °C	mm²/s	14.7	DIN 51562-1	14.7 mm²/s DIN 51562-1
Viscosity at 40 °C	mm²/s	99.3	DIN 51562-1	99.3 mm²/s DIN 51562-1
Viscosity Index VI		153	DIN ISO 2909	153 DIN ISO 2909
HTHS Viscosity at 150 °C	mPa*s	4.1	ASTM D5481	4.1 mPa*s ASTM D5481
CCS Viscosity at -25 °C	mPa*s	6600	ASTM D5293	6600 mPa*s ASTM D5293
Low Temp. Pumping viscosity (MRV) at -30 °C	mPa*s	19.700	ASTM D4684	19.700 mPa*s ASTM D4684
Pourpoint	°C	-39	DIN ISO 3016	-39 °C DIN ISO 3016
Noack Volatility	%	6.7	ASTM D5800	6.7 % ASTM D5800
Flashpoint	°C	249	DIN EN ISO 2592	249 °C DIN EN ISO 2592
tbn	mgKOH/g	10.4	ASTM D2896	10.4 mgKOH/g ASTM D2896
Sulphated Ash	%wt.	0.87	DIN 51575	0.87 %wt. DIN 51575
Approvals		DAF HP-2, Deutz DQC IV-10 LA, DTFR 15C110, Mack EO-N, MAN M 3277, MAN M 3477, MB 228.51, MTU Type 3, MTU Type 3.1, Renault RLD-2, Renault RXD, Scania LDF, Tatra TDS 30/12, Volvo VDS-3		DAF HP-2, Deutz DQC IV-10 LA, DTFR 15C110, Mack EO-N, MAN M 3277, MAN M 3477, MB 228.51, MTU Type 3, MTU Type 3.1, Renault RLD-2, Renault RXD, Scania LDF, Tatra TDS 30/12, Volvo VDS-3

Low Emission Truck 15W-40

For engine

RAVENOL Low Emission Truck SAE 15W-40 can be used in new engines and also in older models.

Manufacturer Approved:
Cummins CES 20081, DDC 93K218, Mack EO-O Premium Plus, Renault RLD-3, Tatra TDS 30/12, Volvo VDS-4

Compliance with the requirements:
Caterpillar ECF-2, Caterpillar ECF-3, Chrysler MS-10902, DDC 93K214, DTFR 15C100 (MB 228.31), Ford WSS-M2C 171-E, Japan Ultra-Low PM Emission Diesel, John Deere JDQ-78 X, MAN M 3271-1, MAN M 3477, MAN M 3575, MB 228.31, MTU Type 2.1, U.S. EPA Tier 3 emissions regulation

show details

SAE: 15W-40

API: CJ-4, SM, SN

ACEA: E7, E9, E11

Available packaging
Full description
Product parameters

Volume:
1 L

vendor code:
1123100-001

Volume:
10 L

vendor code:
1123100-010

Code:
4014835726048

Volume:
20 L

vendor code:
1123100-020

Code:
4014835726024

Volume:
20 L, ecobox

vendor code:
1123100-B20

Volume:
60 L

vendor code:
1123100-060

Code:
4014835726062

Volume:
60 L, print

vendor code:
1123100-D60

Volume:
208 L

vendor code:
1123100-208

Code:
4014835726086

Volume:
208 L, print

vendor code:
1123100-D28

Volume:
1000 L

vendor code:
1123100-700

Volume:
5 L

vendor code:
1123100-005

RAVENOL Low Emission Truck SAE 15W-40 can be used in new engines and also in older models.

RAVENOL Low Emission Truck SAE 15W-40 reduces friction, wear and fuel consumption.

RAVENOL Low Emission Truck SAE 15W-40 improves performance, reliability and cleanliness of the engines.

RAVENOL Low Emission Truck SAE 15W-40 can be used in diesel and petrol engines and reduces the decision with the oil choice. Lower API specifications API CI-4 PLUS, CI-4, CH-4, CG-4, CF-4 are included in API CJ-4 specification.

Application Note

RAVENOL Low Emission Truck SAE 15W-40 is suitable for use in EURO 5 engines with exhaust systems and in EURO 3 and EURO 4 engines if required by the engine manufacturer.

RAVENOL Low Emission Truck SAE 15W-40 is suitable for use in trucks with EGR (Exhaust Gas Recirculation) and SCR (Selective Catalytic Reduction) with ULSD (maximum 15 ppm sulphur) and conventional diesel (500 ppm sulphur) from Volvo, Mack, Renault, MAN, Iveco, Daimler, DAF, Caterpillar, Komatsu for DPF (Diesel Particulate Filter) as DPD (Diesel Particulate defuser) by ISUZU, MAZDA, NISSAN and DPR (Diesel Particulate active Reduction) of HINO and TOYOTA.

RAVENOL Low Emission Truck SAE 15W-40 is also suitable for use in Nonroad Diesel Engines and in engines EU Step IIA, IIB, IV and US Tier 3, Tier 4 Interim, Tier 4 Final with Biodiesel.

Characteristics

Excellent protection of the engine after a cold start and under tougher conditions.
A fast lubrication and sufficiently thick lubricant film at low temperatures is guaranteed.
Security against formation of sludge, carbon deposits, varnish and corrosion, even under adverse conditions.
Prevention of premature DPF (diesel particulate filter)-constipation and reduces the maintenance intervals.
Neutrality towards sealing materials.
A very stable and excellent viscosity behaviour.
An excellent shear stability.
Good detergent and dispersing properties. Protection from foaming.
Outstanding wear and corrosion protection (even at long periods), high oxidation stability, maximum engine cleanliness.
Extended oil change intervals and supports the behaviour at low temperatures
Reduces deposits on the valves to improve engine protection and support to the engine power and fuel performance.

Parameter	Unit	Value	Audit
Recommendations		Caterpillar ECF-2, Caterpillar ECF-3, Chrysler MS-10902, Detroit Diesel DDC 93K214, DTFR 15C100 (MB 228.31), EURO IV, EURO V, Ford WSS-M2C171-E, Japan Ultra-Low PM Emission Diesel, JASO DH-2, John Deere JDQ-78X Oxidations Test, MAN M 3271-1, MAN M 3477, MAN M 3575, MB 228.31, MTU Typ 2.1, U.S. EPA Tier 3 emissions regulation		Caterpillar ECF-2, Caterpillar ECF-3, Chrysler MS-10902, Detroit Diesel DDC 93K214, DTFR 15C100 (MB 228.31), EURO IV, EURO V, Ford WSS-M2C171-E, Japan Ultra-Low PM Emission Diesel, JASO DH-2, John Deere JDQ-78X Oxidations Test, MAN M 3271-1, MAN M 3477, MAN M 3575, MB 228.31, MTU Typ 2.1, U.S. EPA Tier 3 emissions regulation
SAE		15W-40		15W-40
Brand		RAVENOL		RAVENOL
Type		Semi-synthetic		Semi-synthetic
API		CJ-4, SM, SN		CJ-4, SM, SN
ACEA		E11, E7, E9		E11, E7, E9
JASO		DH-2		DH-2
Manufacturer Approved		Cummins CES 20081, DDC 93K218, Mack EO-O Premium Plus, Renault RLD-3, Tatra TDS 30/12, Volvo VDS-4		Cummins CES 20081, DDC 93K218, Mack EO-O Premium Plus, Renault RLD-3, Tatra TDS 30/12, Volvo VDS-4
Recomendations		Caterpillar ECF-2, Caterpillar ECF-3, Chrysler MS-10902, DDC 93K214, DTFR 15C100 (MB 228.31), Ford WSS-M2C 171-E, Japan Ultra-Low PM Emission Diesel, John Deere JDQ-78 X, MAN M 3271-1, MAN M 3477, MAN M 3575, MB 228.31, MTU Type 2.1, U.S. EPA Tier 3 emissions regulation		Caterpillar ECF-2, Caterpillar ECF-3, Chrysler MS-10902, DDC 93K214, DTFR 15C100 (MB 228.31), Ford WSS-M2C 171-E, Japan Ultra-Low PM Emission Diesel, John Deere JDQ-78 X, MAN M 3271-1, MAN M 3477, MAN M 3575, MB 228.31, MTU Type 2.1, U.S. EPA Tier 3 emissions regulation
Density at 20 °C	g/cm³	862	EN ISO 12185	862 g/cm³ EN ISO 12185
Color		Brown	visual	Brown visual
Viscosity at 100 °C	mm²/s	14.5	DIN 51562-1	14.5 mm²/s DIN 51562-1
Viscosity at 40 °C	mm²/s	101.5	DIN 51562-1	101.5 mm²/s DIN 51562-1
Viscosity Index VI		148	DIN ISO 2909	148 DIN ISO 2909
CCS Viscosity at -20 °C	mPa*s	4310	ASTM D5293	4310 mPa*s ASTM D5293
Pourpoint	°C	-39	DIN ISO 3016	-39 °C DIN ISO 3016
Flashpoint	°C	240	DIN EN ISO 2592	240 °C DIN EN ISO 2592
tbn	mgKOH/g	8.2	ASTM D2896	8.2 mgKOH/g ASTM D2896
Sulphated Ash	%wt.	0.92	DIN 51575	0.92 %wt. DIN 51575
Approvals		Caterpillar ECF-2, Caterpillar ECF-3, Chrysler MS-10902, Cummins CES 20081, DDC 93K214, DDC 93K218, DTFR 15C100 (MB 228.31), Ford WSS-M2C 171-E, Japan Ultra-Low PM Emission Diesel, John Deere JDQ-78 X, Mack EO-O Premium Plus, MAN M 3271-1, MAN M 3477, MAN M 3575, MB 228.31, MTU Type 2.1, Renault RLD-3, Tatra TDS 30/12, U.S. EPA Tier 3 emissions regulation, Volvo VDS-4		Caterpillar ECF-2, Caterpillar ECF-3, Chrysler MS-10902, Cummins CES 20081, DDC 93K214, DDC 93K218, DTFR 15C100 (MB 228.31), Ford WSS-M2C 171-E, Japan Ultra-Low PM Emission Diesel, John Deere JDQ-78 X, Mack EO-O Premium Plus, MAN M 3271-1, MAN M 3477, MAN M 3575, MB 228.31, MTU Type 2.1, Renault RLD-3, Tatra TDS 30/12, U.S. EPA Tier 3 emissions regulation, Volvo VDS-4

Central lubrication system BEKA-MAX

Mehrzweckfett mit Graphit

For lubrication

RAVENOL Mehrzweckfett mit Graphit is formulated with a highly refined base oil mixture which contains less than 3% polycyclic aromatics.Through the graphite at high temperatures a lubrication film on the metals is formed, and the graphite takes lubrication to achieve optimal results.

show details

Equivalents OEM:
VAG G060735A2

Available packaging
Full description
Product parameters

Volume:
100 g

vendor code:
1340102-100

Code:
4014835844391

Volume:
200 g

vendor code:
1340102-200

Volume:
400 g

vendor code:
1340102-400

Code:
4014835768147

Volume:
1 kg

vendor code:
1340102-001

Code:
4014835200210

Volume:
5 kg

vendor code:
1340102-005

Code:
4014835200265

Volume:
10 kg

vendor code:
1340102-010

Code:
4014835200227

Volume:
15 kg

vendor code:
1340102-015

Volume:
25 kg

vendor code:
1340102-025

Code:
4014835200258

Volume:
180 kg

vendor code:
1340102-180

Code:
4014835200272

RAVENOL Mehrzweckfett mit Graphit is formulated with a highly refined base oil mixture which contains less than 3% polycyclic aromatics.Through the graphite at high temperatures a lubrication film on the metals is formed, and the graphite takes lubrication to achieve optimal results.

The optimized formulation of RAVENOL Mehrzweckfett mit Graphit can also capture temperature peaks in the application.

Application Note

RAVENOL Mehrzweckfett mit Graphit has been designed for applications exposed to high temperatures and shock loads.

RAVENOL Mehrzweckfett mit Graphit is used in oven conveyor belts, pistons in hydraulic pumps and all types of bearings that run at low speeds.

RAVENOL Mehrzweckfett mit Graphit is also used as a sealant in high temperature gaskets from steam pipes and other hot pipe connections.

Characteristics

Extreme shear stability
Excellent corrosion protection
Very good mechanical and chemical stability
Very good aging resistant
Good pump output also at low temperatures

Parameter	Unit	Value	Audit
Brand		RAVENOL		RAVENOL
specification		DIN 51502 KPF2K-30, ISO I6743-9: ISO-L-XCCFB2		DIN 51502 KPF2K-30, ISO I6743-9: ISO-L-XCCFB2
Color		Black gray	visual	Black gray visual
Thickener		lithium soap	DIN 51757	lithium soap DIN 51757
Additives		graphite	DIN 51757	graphite DIN 51757
NLGI-Class		2	DIN 51818	2 DIN 51818
Product Classification		KPF2K-30	DIN 51502	KPF2K-30 DIN 51502
Working Temperature	°C	-30 / +120	DIN 51825	-30 / +120 °C DIN 51825
Short term temperature up to	°C	130	DIN 51757	130 °C DIN 51757
Worked Penetration at 60 Strokes		265-295	ISO 2137	265-295 ISO 2137
Corrosion (SKF Emcor dist. Water)		1	DIN 51802	1 DIN 51802
Dropping Point	°C	180 —	DIN ISO 2176	180 — °C DIN ISO 2176
Copper Corrosion (24h/120 °C)		1	DIN 51811	1 DIN 51811
Water Resistance (3h/90 °C)	°C	1-90	DIN 51807-1	1-90 °C DIN 51807-1
VKA Pressure Carrying Capacity	N	2000 — 2200	DIN 51350-4	2000 — 2200 N DIN 51350-4
Kinematic Viscosity (Base Oil) at 40 °C	mm²/s	80	DIN 51562-1	80 mm²/s DIN 51562-1
Approvals		DIN 51502 KPF2K-30, ISO I6743-9: ISO-L-XCCFB2		DIN 51502 KPF2K-30, ISO I6743-9: ISO-L-XCCFB2

Mehrzweckfett OML

For lubrication

RAVENOL Mehrzweckfett OML has an extreme mechanical stability and a very low friction value. Therefore it can be transported easily.

show details

Equivalents OEM:
Alpine 0101001, Alpine 0101002, Alpine 0101003, Alpine 0101004, Alpine 0101005, Alpine 0101005

Available packaging
Full description
Product parameters

Volume:
100 g

vendor code:
1340101-100

Code:
4014835844339

Volume:
200 g

vendor code:
1340101-200

Volume:
400 g

vendor code:
1340101-400

Code:
4014835768048

Volume:
5 kg

vendor code:
1340101-005

Code:
4014835200159

Volume:
10 kg

vendor code:
1340101-010

Code:
4014835200111

Volume:
15 kg

vendor code:
1340101-015

Volume:
25 kg

vendor code:
1340101-025

Code:
4014835200128

Volume:
180 kg

vendor code:
1340101-180

Code:
4014835200142

RAVENOL Mehrzweckfett OML has an extreme mechanical stability and a very low friction value. Therefore it can be transported easily.

Application Note

RAVENOL Mehrzweckfett OML is used for the lubrication of easy loaded antifriction bearings and machine components. It is also suited as multipurpose lubrication grease for vehicles.

Characteristics

Universal use, multipurpose characteristic for a mixed car pool
Extreme shear stability
Excellent corrosion protection
Excellent wear protection
Very good mechanical and chemical stability
Very good aging resistant
Good pumpability, even at low temperatures

Parameter	Unit	Value	Audit
Brand		RAVENOL		RAVENOL
specification		DIN 51502 K2K-30, ISO 6743-9: ISO-L-XCCEA2		DIN 51502 K2K-30, ISO 6743-9: ISO-L-XCCEA2
Color		Light brown	visual	Light brown visual
Thickener		lithium soap	DIN 51757	lithium soap DIN 51757
NLGI-Class		2	DIN 51818	2 DIN 51818
Product Classification		K2K-30	DIN 51502	K2K-30 DIN 51502
Working Temperature	°C	-30 / +120	DIN 51825	-30 / +120 °C DIN 51825
Short term temperature up to	°C	130	DIN 51757	130 °C DIN 51757
Worked Penetration at 60 Strokes		265-295	ISO 2137	265-295 ISO 2137
Corrosion (SKF Emcor dist. Water)		1	DIN 51802	1 DIN 51802
Dropping Point	°C	180 —	DIN ISO 2176	180 — °C DIN ISO 2176
Copper Corrosion (24h/120 °C)		1	DIN 51811	1 DIN 51811
Water Resistance (3h/90 °C)	°C	1-90	DIN 51807-1	1-90 °C DIN 51807-1
VKA Pressure Carrying Capacity	N	2000 — 2200	DIN 51350-4	2000 — 2200 N DIN 51350-4
Kinematic Viscosity (Base Oil) at 40 °C	mm²/s	130	DIN 51562-1	130 mm²/s DIN 51562-1
Approvals		DIN 51502 K2K-30, ISO 6743-9: ISO-L-XCCEA2		DIN 51502 K2K-30, ISO 6743-9: ISO-L-XCCEA2

Mehrzweckfett mit MoS2

For CV joint

RAVENOL Mehrzweckfett mit MoS2 is formulated with a highly refined base oil mixture which contains less than 3% polycyclic aromatics.

show details

Equivalents OEM:
Alpine 0101061, Alpine 0101062, Alpine 0101063, Alpine 0101064, Alpine 0101065, Alpine 0101066, BMW 83230417754, FEBI 02582, FEBI 02597, FEBI 2582, FEBI 2597, Ford 1019761, Ford 1720193, Hyundai Motor 4959022B00A, MB A001989035112, Polaris 2871515, Polaris 2871551, Polaris 2871551, SWAG 99830001, VAG G052172A2, VAG G052723A2, Yamalube ACCMOLDMGS10

Available packaging
Full description
Product parameters

Volume:
100 g

vendor code:
1340103-100

Code:
4014835844452

Volume:
200 g

vendor code:
1340103-200

Volume:
400 g

vendor code:
1340103-400

Code:
4014835768246

Volume:
1 kg

vendor code:
1340103-001

Code:
4014835200333

Volume:
5 kg

vendor code:
1340103-005

Code:
4014835200357

Volume:
10 kg

vendor code:
1340103-010

Code:
4014835200319

Volume:
15 kg

vendor code:
1340103-015

Volume:
25 kg

vendor code:
1340103-025

Code:
4014835200326

Volume:
180 kg

vendor code:
1340103-180

Code:
4014835200371

RAVENOL Mehrzweckfett mit MoS2 is formulated with a highly refined base oil mixture which contains less than 3% polycyclic aromatics.

The optimized formulation of RAVENOL Mehrzweckfett mit MoS2 has distinctive friction-reducing properties and so-called dry running properties.

Application Note

RAVENOL Mehrzweckfett mit MoS2 has been designed for applications exposed to extreme pressure and shock loaded bearings with relatively slow sliding movements.

RAVENOL Mehrzweckfett mit MoS2 is recommended for friction and roller bearings of all types during aggravated operating conditions.

RAVENOL Mehrzweckfett mit MoS2 is also used for chassis lubricating.

Characteristics

Extreme shear stability
Excellent corrosion protection
Very good mechanical and chemical stability
Very good aging resistant
Good pump output also at low temperatures

Parameter	Unit	Value	Audit
Brand		RAVENOL		RAVENOL
specification		DIN 51502 KPF2K-30, ISO 6743-9: ISO-L-XCCIB2		DIN 51502 KPF2K-30, ISO 6743-9: ISO-L-XCCIB2
Color		Black gray	visual	Black gray visual
Thickener		lithium soap	DIN 51757	lithium soap DIN 51757
Additives		molybdenum disulfide	DIN 51757	molybdenum disulfide DIN 51757
NLGI-Class		2	DIN 51818	2 DIN 51818
Product Classification		KPF2K-30	DIN 51502	KPF2K-30 DIN 51502
Working Temperature	°C	-30 / +120	DIN 51825	-30 / +120 °C DIN 51825
Short term temperature up to	°C	130	DIN 51757	130 °C DIN 51757
Worked Penetration at 60 Strokes		265-295	ISO 2137	265-295 ISO 2137
Corrosion (SKF Emcor dist. Water)		1	DIN 51802	1 DIN 51802
Dropping Point	°C	180 —	DIN ISO 2176	180 — °C DIN ISO 2176
Copper Corrosion (24h/120 °C)		1	DIN 51811	1 DIN 51811
Water Resistance (3h/90 °C)	°C	1-90	DIN 51807-1	1-90 °C DIN 51807-1
VKA Pressure Carrying Capacity	N	2800 — 3000	DIN 51350-4	2800 — 3000 N DIN 51350-4
Kinematic Viscosity (Base Oil) at 40 °C	mm²/s	80	DIN 51562-1	80 mm²/s DIN 51562-1
Approvals		DIN 51502 KPF2K-30, ISO 6743-9: ISO-L-XCCIB2		DIN 51502 KPF2K-30, ISO 6743-9: ISO-L-XCCIB2

Central lubrication system Groeneveld

KFZ-Fliessfett ZSA

For lubrication

Application NoteRAVENOL KFZ-Fließfett ZSA is recommended by Willy Vogel, Mercedes-Benz and MAN for central lubricating equipment.

Manufacturer Approved:
MAN 283 Li-P 00, MAN 283 Li-P 000, MB-Approval 264.0

Compliance with the requirements:
DTFR 33B100 (MB 264.0)

show details

Equivalents OEM:
Alpine 0101083, Alpine 0101084, Alpine 0101085, Alpine 0101085, Alpine 0101089, FEBI 03514, FEBI 3514

Available packaging
Full description
Product parameters

Volume:
1 kg

vendor code:
1340107-001

Volume:
5 kg

vendor code:
1340107-005

Code:
4014835201156

Volume:
10 kg

vendor code:
1340107-010

Code:
4014835201118

Volume:
15 kg

vendor code:
1340107-015

Volume:
25 kg

vendor code:
1340107-025

Code:
4014835201125

Volume:
180 kg

vendor code:
1340107-180

Code:
4014835201170

Application Note

RAVENOL KFZ-Fließfett ZSA is recommended by Willy Vogel, Mercedes-Benz and MAN for central lubricating equipment.

Characteristics

Very good thermic stability
Very good adhesion on metallic surfaces
Excellent pump output, also at low temperatures
Very good corrosion and oxidation protection
Extreme shear stability
Can be transported in case of changing climatically conditions over long distances and small section

Parameter	Unit	Value	Audit
Recommendations		DTFR 33B100 (MB 264.0)		DTFR 33B100 (MB 264.0)
Brand		RAVENOL		RAVENOL
Manufacturer Approved		MAN 283 Li-P 00, MAN 283 Li-P 000, MB-Approval 264.0		MAN 283 Li-P 00, MAN 283 Li-P 000, MB-Approval 264.0
Recomendations		DTFR 33B100 (MB 264.0)		DTFR 33B100 (MB 264.0)
specification		DIN 51502 GP00K-30, ISO 6743-9: ISO-L-XCCEB00		DIN 51502 GP00K-30, ISO 6743-9: ISO-L-XCCEB00
Color		Green	visual	Green visual
Thickener		lithium soap	DIN 51757	lithium soap DIN 51757
NLGI-Class		00	DIN 51818	00 DIN 51818
Product Classification		GP00K-30	DIN 51502	GP00K-30 DIN 51502
Working Temperature	°C	-30 / +120	DIN 51825	-30 / +120 °C DIN 51825
Short term temperature up to	°C	120	DIN 51757	120 °C DIN 51757
Worked Penetration at 60 Strokes		400-430	ISO 2137	400-430 ISO 2137
Corrosion (SKF Emcor dist. Water)		1	DIN 51802	1 DIN 51802
Dropping Point	°C	185	DIN ISO 2176	185 °C DIN ISO 2176
Copper Corrosion (24h/120 °C)		1	DIN 51811	1 DIN 51811
Water Resistance (3h/90 °C)	°C	1-90	DIN 51807-1	1-90 °C DIN 51807-1
VKA Pressure Carrying Capacity	N	— 2000	DIN 51350-4	— 2000 N DIN 51350-4
Kinematic Viscosity (Base Oil) at 40 °C	mm²/s	40	DIN 51562-1	40 mm²/s DIN 51562-1
Approvals		DIN 51502 GP00K-30, DTFR 33B100 (MB 264.0), ISO 6743-9: ISO-L-XCCEB00, MAN 283 Li-P 00, MAN 283 Li-P 000, MB 264.0		DIN 51502 GP00K-30, DTFR 33B100 (MB 264.0), ISO 6743-9: ISO-L-XCCEB00, MAN 283 Li-P 00, MAN 283 Li-P 000, MB 264.0

Cooling system

Liquid volume (basic): 52 L

LTC - Protect C12++ Premix -40°C

Coolant

RAVENOL LTC Lobrid Technology Coolant Premix -40°C is free from 2-ethylhexanoic acid, borate, nitrite, amine and phosphate.

Compliance with the requirements:
Chrysler MS-90032, DTFR 29C120 (MB 325.5), DTFR 29D120 (MB 326.5), MAN 324 Type Si-OAT, MB 325.5, MB 326.6, Scania TB 1451, VW G 012 A8G, VW G 013 A8J, VW TL 774-G, VW TL 774-J

show details

Available packaging
Full description
Product parameters

Volume:
1.5 L

vendor code:
1410126-150

Code:
4014835756113

Volume:
5 L

vendor code:
1410126-005

Code:
4014835756151

Volume:
10 L

vendor code:
1410126-010

Volume:
20 L

vendor code:
1410126-020

Code:
4014835756120

Volume:
20 L, ecobox

vendor code:
1410126-B20

Code:
4014835858893

Volume:
208 L

vendor code:
1410126-208

Code:
4014835756182

Volume:
1000 L

vendor code:
1410126-700

Volume:
60 L

vendor code:
1410126-060

Code:
4014835756168

RAVENOL LTC Lobrid Technology Coolant Premix -40°C is free from 2-ethylhexanoic acid, borate, nitrite, amine and phosphate.

The quality of an antifreeze is no longer just determined by the antifreeze effect (which automatically exists in an ethylene-glycol based product), but by the rust protection.

That is why manufacturers subject antifreeze to lengthy corrosion and cavitation tests.

RAVENOL LTC Lobrid Technology Coolant Premix -40°C protects the cooling system from rust, frost, and in summer, from overheating.

Application Note

RAVENOL LTC Lobrid Technology Coolant Premix -40°C is a prediluted coolant with frost and rust protection for year-round use in automotive engines.

Even in summer coolant must contain enough antifreeze to ensure good corrosion and overheating protection.

Instructions: Add RAVENOL LTC Lobrid Technology Coolant Premix -40°C to radiator to fill line.

Characteristics

Excellent for all-aluminium engines
Good reserve alkalinity
Premium corrosion additives for optimal rust protection for all metals and metal alloys used in cooling systems, including aluminium
Prevents sediments and foaming in the cooling system
Compatible with elastomers used in automotive radiators
Can be mixed with other coolant types

Parameter	Unit	Value	Audit
Recommendations		Chrysler MS-90032, DTFR 29C120 (MB 325.5), DTFR 29D120 (MB 326.5), MAN 324 Si-OAT, MB (A 000 989 08 25 10), MB 325.5, MB 326.6 (Premix), Mopar 68163848AA, Mopar 68163849AA, Scania TB 1451, VW G 012 A8G M1, VW G 012 A8G M8, VW G 012 A8G M9, VW G 013 A8J M1, VW G 013 A8J M8, VW G 013 A8J M9, VW TL 774-G (entspricht G12++), VW TL 774-J (entspricht G13)		Chrysler MS-90032, DTFR 29C120 (MB 325.5), DTFR 29D120 (MB 326.5), MAN 324 Si-OAT, MB (A 000 989 08 25 10), MB 325.5, MB 326.6 (Premix), Mopar 68163848AA, Mopar 68163849AA, Scania TB 1451, VW G 012 A8G M1, VW G 012 A8G M8, VW G 012 A8G M9, VW G 013 A8J M1, VW G 013 A8J M8, VW G 013 A8J M9, VW TL 774-G (entspricht G12++), VW TL 774-J (entspricht G13)
Brand		RAVENOL		RAVENOL
Recomendations		Chrysler MS-90032, DTFR 29C120 (MB 325.5), DTFR 29D120 (MB 326.5), MAN 324 Type Si-OAT, MB 325.5, MB 326.6, Scania TB 1451, VW G 012 A8G, VW G 013 A8J, VW TL 774-G, VW TL 774-J		Chrysler MS-90032, DTFR 29C120 (MB 325.5), DTFR 29D120 (MB 326.5), MAN 324 Type Si-OAT, MB 325.5, MB 326.6, Scania TB 1451, VW G 012 A8G, VW G 013 A8J, VW TL 774-G, VW TL 774-J
Compliant products		MB A 000 989 08 25 10, Mopar 68163848AA, Mopar 68163849AA, VW G 012 A8G, VW G 013 A8J		MB A 000 989 08 25 10, Mopar 68163848AA, Mopar 68163849AA, VW G 012 A8G, VW G 013 A8J
Density at 20 °C	g/cm³	1079	EN ISO 12185	1079 g/cm³ EN ISO 12185
Color		Violet	visual	Violet visual
pH - value at 20 °C		8,2	ASTM D1287	8,2 ASTM D1287
Freezing point	°C	-40	ASTM D1177	-40 °C ASTM D1177
Approvals		Chrysler MS-90032, DTFR 29C120 (MB 325.5), DTFR 29D120 (MB 326.5), MAN 324 Type Si-OAT, MB 325.5, MB 326.6, Scania TB 1451, VW G 012 A8G, VW G 013 A8J, VW TL 774-G, VW TL 774-J		Chrysler MS-90032, DTFR 29C120 (MB 325.5), DTFR 29D120 (MB 326.5), MAN 324 Type Si-OAT, MB 325.5, MB 326.6, Scania TB 1451, VW G 012 A8G, VW G 013 A8J, VW TL 774-G, VW TL 774-J

LTC - Protect C12++ Concentrate

Coolant

RAVENOL LTC Lobrid Technology Coolant Concentrate is free from 2-ethylhexanoic acid, borate, nitrite, amine and phosphate.

Compliance with the requirements:
Chrysler MS-90032, DTFR 29C120 (MB 325.5), MAN 324 Type Si-OAT, MB 325.5, MB 325.6, Scania TB 1451, VW G 012 A8G, VW G 013 A8J, VW TL 774-G, VW TL 774-J

show details

Attention! This is a concentrated product. Before use, it must be diluted with distilled water in a 1:1 ratio.

Available packaging
Full description
Product parameters

Volume:
1.5 L

vendor code:
1410125-150

Code:
4014835756014

Volume:
5 L

vendor code:
1410125-005

Code:
4014835756052

Volume:
10 L

vendor code:
1410125-010

Volume:
20 L

vendor code:
1410125-020

Code:
4014835756021

Volume:
20 L, ecobox

vendor code:
1410125-B20

Volume:
60 L

vendor code:
1410125-060

Volume:
208 L

vendor code:
1410125-208

Volume:
1000 L

vendor code:
1410125-700

RAVENOL LTC Lobrid Technology Coolant Concentrate is free from 2-ethylhexanoic acid, borate, nitrite, amine and phosphate.

The quality of an antifreeze is no longer just determined by the antifreeze effect (which automatically exists in an ethylene-glycol based product), but by the rust protection.

That is why manufacturers subject antifreeze to lengthy corrosion and cavitation tests.

RAVENOL LTC Lobrid Technology Coolant Concentrate protects the cooling system from corrosion, frost, and in the summer from overheating.

Application Note

RAVENOL LTC Lobrid Technology Coolant Concentrate with frost and rust protection for year-round use in all-aluminium engines. Use according to the mixing chart. Follow manufacturer’s recommendations.

Instructions: Clean cooling system, check for leaks, flush.

Mix RAVENOL LTC Lobrid Technology Coolant Concentrate with distilled water (per mixing table) and add. Allow engine and heater to warm up, add coolant to fill level.

Table of mixing ratios
Antifreeze protection until	Parts Antifreeze	Parts Water
-20°C	35%	65%
-37°C	50%	50%
-50°C	60%	40%

Characteristics

Excellent for all-aluminium engines
Good reserve alkalinity
Premium corrosion additives for optimal rust protection for all metals and metal alloys used in coolsystems, including aluminium
Prevents sediments and foaming in the cooling system
Compatible with elastomers used in automotive radiators
Can be mixed with other coolant types

Parameter	Unit	Value	Audit
Recommendations		Chrysler MS-90032, DTFR 29C120 (MB 325.5), MAN 324 Si-OAT, MB 325.5, MB 325.6, Mopar 68163848AA, Mopar 68163849AA, Scania TB 1451, VW G 012 A8G M1, VW G 012 A8G M8, VW G 012 A8G M9, VW G 013 A8J M1, VW G 013 A8J M8, VW G 013 A8J M9, VW TL 774-G (entspricht G12++), VW TL 774-J (entspricht G13)		Chrysler MS-90032, DTFR 29C120 (MB 325.5), MAN 324 Si-OAT, MB 325.5, MB 325.6, Mopar 68163848AA, Mopar 68163849AA, Scania TB 1451, VW G 012 A8G M1, VW G 012 A8G M8, VW G 012 A8G M9, VW G 013 A8J M1, VW G 013 A8J M8, VW G 013 A8J M9, VW TL 774-G (entspricht G12++), VW TL 774-J (entspricht G13)
Brand		RAVENOL		RAVENOL
Recomendations		Chrysler MS-90032, DTFR 29C120 (MB 325.5), MAN 324 Type Si-OAT, MB 325.5, MB 325.6, Scania TB 1451, VW G 012 A8G, VW G 013 A8J, VW TL 774-G, VW TL 774-J		Chrysler MS-90032, DTFR 29C120 (MB 325.5), MAN 324 Type Si-OAT, MB 325.5, MB 325.6, Scania TB 1451, VW G 012 A8G, VW G 013 A8J, VW TL 774-G, VW TL 774-J
Compliant products		Mopar 68163848AA, Mopar 68163849AA, VW G 012 A8G, VW G 013 A8J		Mopar 68163848AA, Mopar 68163849AA, VW G 012 A8G, VW G 013 A8J
Density at 20 °C	g/cm³	1120	EN ISO 12185	1120 g/cm³ EN ISO 12185
Color		Violet	visual	Violet visual
Reserve alkalinity	mgKOH/g	5.5 —	ASTM D1120	5.5 — mgKOH/g ASTM D1120
Boiling point	°C	175 —	ASTM D1121	175 — °C ASTM D1121
Water content	%	— 5	ASTM D1123	— 5 % ASTM D1123
Flashpoint	°C	115	DIN 51758	115 °C DIN 51758
Freezing point (50 % solution)	°C	-37	ASTM D1177	-37 °C ASTM D1177
pH - value at 20 °C (50 Vol %)		8,1	ASTM D1287	8,1 ASTM D1287
Approvals		Chrysler MS-90032, DTFR 29C120 (MB 325.5), MAN 324 Type Si-OAT, MB 325.5, MB 325.6, Scania TB 1451, VW G 012 A8G, VW G 013 A8J, VW TL 774-G, VW TL 774-J		Chrysler MS-90032, DTFR 29C120 (MB 325.5), MAN 324 Type Si-OAT, MB 325.5, MB 325.6, Scania TB 1451, VW G 012 A8G, VW G 013 A8J, VW TL 774-G, VW TL 774-J

Destilliertes Wasser (entionisiert)

For batteries

In the course of this process, the water flows through a column filled with ion exchange resin. This has theability to exchange its accumulated ions for the ions present in the water.

Compliance with the requirements:
DIN 43530-4, DIN EN 50272

show details

Equivalents OEM:
BMW 83190394350, BMW 83190394350

Available packaging
Full description
Product parameters

Volume:
1 L

vendor code:
1360010-001

Code:
4014835300453

Volume:
5 L

vendor code:
1360010-005

Code:
4014835300507

Volume:
5 L, specialist. canister

vendor code:
1360010-005

Code:
4014835300514

Volume:
20 L

vendor code:
1360010-020

Code:
4014835300422

Volume:
208 L

vendor code:
1360010-208

Volume:
1000 L

vendor code:
1360010-700

In the course of this process, the water flows through a column filled with ion exchange resin. This has theability to exchange its accumulated ions for the ions present in the water.

As the ion exchange resin cannot accumulate an infinite number of ions, they have to be “revived”, i.e. theyhave to be regenerated. This takes place using the currently most commonly used regeneration agents: sodiumchloride (water softening), hydrochloric acid (cation exchange) and sodium hydroxide (anion exchange).The conductivity of the water flowing through is constantly checked in a fully automated process and the ionexchanger unit regulates itself automatically.

RAVENOL destilliertes Wasser deionised water is regularly checked by taking samples.

Application Note

RAVENOL destilliertes Wasser is ideally suited to filling up vehicle batteries and for steam irons and aquariums (to reduce the hardness of the water).

Parameter	Value
Recommendations	DIN 43 530-4 Akkumulatoren, DIN EN 50272, Elektrolyt und Nachfüllwasser	DIN 43 530-4 Akkumulatoren, DIN EN 50272, Elektrolyt und Nachfüllwasser
Brand	RAVENOL	RAVENOL
Recomendations	DIN 43530-4, DIN EN 50272	DIN 43530-4, DIN EN 50272
Approvals	DIN 43530-4, DIN EN 50272	DIN 43530-4, DIN EN 50272
